Female D Sub Connector High Density Class IO Connector 25mΩ Max
Price:
Negotiation
MOQ:
1000pcs
Delivery Time:
15-25 Working Days
Brand:
WCON
Product Description
High density D-SUB Connector Female Blue 8.89mm Footprint Right angle TYPE
| Current Rating | 3.0AMP |
| Contact Resistance | 25mΩ Max |
| Withstand Voltage | 500V AC/DC |
| Insulation Resistance | 1000mΩ Min |
| Operation Temperature | ﹣55℃ to +105℃ |
| Housing Material | PBT+30%GF(UL94V-0) |
| Contact Material | Coppy alloy |
| Contact Plating | Au/Sn over Ni Plating |
| Shell | Cold Roller Steel,Ni Plated |
| Revit/Harpoon | Brass,Sn Over Ni Plated |
| Screw | Brass,Ni Plated |
Product Name: D-SUB connector
1. Features: the use of a wide range of environmental protection fireproof antioxidant electrical conductivity and long service life force is strong.
2. Material: PBT (green, black, white) plus fiber 30% UL94V-0 contact body material: brass (C3604)
3. Scope of application: used for connecting a computer, communication, medical equipment, wire and cable, aviation, digital, machinery and equipment, game consoles and other integrated circuit package pins and printed circuit board.
