WCON IO Connector for Computer 15 Pin D-Type Connector Female Connectors

Price Negotiable
Price: Negotiation
MOQ: 1000pcs
Delivery Time: 15-25 Working Days
Brand: WCON
Product Description

Slim HD R 15P Female,DIP D-SUB Short 9 Pin IO connector for computer



Current Rating 3.0AMP
Contact Resistance 25mΩ Max
Withstand Voltage 500V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣55℃ to +105℃
Contact Material Brass
Contact Plating Au Or Sn over Ni
Insulator Material PA66+30%GF UL94V-0
Shell Cold Roller Steel,Ni Plated
Revit/Harpoon Brass,Sn Over Ni Plated



Product Name: D-SUB connector



1. features: the use of a wide range of environmental protection fireproof antioxidant electrical conductivity and long service life force is strong.



2. material: PBT (green, black, white) plus fiber 30% UL94V-0 contact body material: brass (C3604)



3. scope of application: used for connecting a computer, communication, medical equipment, wire and cable, aviation, digital, machinery and equipment, game consoles and other integrated circuit package pins and printed circuit board.









WCON Pcb Pin Male Header Connector Single Row Header 2.00mm 1*22P 180°DIPDrawing:D-SUB 6215A-15FMNXXX01.pdf
