WCON IC Socket 2*10P 180° H=3.0 Round female Header 7.62 with center bar
Price:
Negotiation
MOQ:
1000pcs
Delivery Time:
15-25 Working Days
Brand:
WCON
Product Description
10mΩ Max IC Socket 2*10P 180° H=3.0,L=4.2 Row of Pitch 7.62 with center bar
| Current Rating | 1.0AMP |
| Contact Resistance | 10mΩ Max |
| Dielectric Strength | Min 1000VRMS |
| Mechanical Life | Min 100 cycles |
| Mating Pin | Φ0.40 to Φ0.56mm |
| Forces | polished steel gauga Φ0.43mm |
| Insertion | 200g Max/Pin, Withdrawal:60g Min/Pin |
| Operation Temperature | ﹣40℃ to +105℃ |
| Sleeve | Brass CuZn36Pb3(C36000),Sn over Ni |
| Contact Clip(4 finger) | BeCu(C17200),Au Or Sn over Ni |
| Insulator Material | PPS+30%GF(UL94V-0) |
| 06~18P | Insulatora without center bar |
| 20~28P | Insulatora with center bar |
| item name:IC Connector | ||
| product features: the use of a wide range of environmental protection, explosion-proof, moisture-proof | ||
| product material: (UL94V-0) PPS black +30%GF | ||
| scope of application: used in all kinds of consumer electronic appliances, electronic communication, power and industrial control, medical equipment, automotive electronics, solar energy and other industries, with the most sophisticated and reliable |
Drawing:IC Socket 7110-301XXSXX074X1.pdf
