H=6.4 2.0 Pitch Box Header Connector Straight PBT Black Gold Flash ROHS

Price Negotiable
Price: netotiation
MOQ: 1000PCS
Delivery Time: 15~25Day
Brand: WCON
Product Description
Current Rating 2.0AMP
Contact Resistance 20mΩ Max
Withstand Voltage 500V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣40℃ to +105℃
Contact Material Brass
Contact Plating Au or Sn over Ni
Insulator Material PA9T +30％GF( UL94V-0 )
CAP Material LCP+30%G.F(UL94V-0)





H=6.4 2.0 Pitch box header connector straight PBT black gold flash ROHS.



 WCON Pcb Pin Male Header Connector Single Row Header 2.00mm 1*22P 180ÃÆ’‚°DIPDrawing:box header 3121-XXSXXBK00X1(H=6.4).pdf
