China SMT Type Connector Pin Header 1.27 Mm Pitch PA9T Black Gold Flash ROHS for sale
China SMT Type Connector Pin Header 1.27 Mm Pitch PA9T Black Gold Flash ROHS for sale
China SMT Type Connector Pin Header 1.27 Mm Pitch PA9T Black Gold Flash ROHS for sale

SMT Type Connector Pin Header 1.27 Mm Pitch PA9T Black Gold Flash ROHS

Price Negotiable
Price: negotiation
MOQ: 1000pcs
Delivery Time: 15~25Day
Brand: WCON
Product Description

  SMT type box header connector 1.27 pitch PA9T black gold flash ROHS.



 WCON Pcb Pin Male Header Connector Single Row Header 2.00mm 1*22P 180ÃÆ’‚°DIPDrawing:box header 3130-XXMXXBK00X1.pdf.



Current Rating 1AMP
Contact Resistance 20mΩ Max
Withstand Voltage 500V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣40℃ to +105℃
Contact Material Brass
Contact Plating Au or Sn over Ni
Insulator Material PA9T +30％GF( UL94V-0 )
