5P 3.50mm Euro Terminal Block Connector with Wire Protection H=8.4 Straight PBT Blue Sn Plated
Price:
negotiation
MOQ:
1000pcs
Delivery Time:
15~25Day
Brand:
WCON
Product Description
5P 3.50mm Euro Terminal Block with Wire Protection H=8.4 Straight,PBT Blue Sn Plated.
| Item name: terminal | ||||||||
| Product features: high switching frequency, high insulation, long service life, high reliability | ||||||||
| Material: copper alloy, copper alloy, nickel or nickel alloy | ||||||||
| Application: mainly used in lighting, communications, security and other industries. The application of industry pluggable terminal blocks is the most main pan, such as frequency, riot, control panel, access controller, sensor, PLC, instrumentation, power, servo drive, the common requirements of these applications of pluggable terminal blocks are: plug to stable contact resistance to be small, to be able to meet the life and fatigue degree, so higher requirements for metal shrapnel materials. This requires the designer to have some experience in structure and material selection. For the fence type terminals are mainly used in: power supply, relay (especially double terminal), inverter, elevator industry (less), air conditioning. |
| 1. Current Rating | 10A |
|
2. Voltage Rating |
150V |
| 3. Contact Resistance | 8milliohm Max |
|
4. Withstand Voltage |
AC/DC 1000V |
| 5. Insulation Resistance | 500Megohm Min |
| 6. Screw Torque | 2.0 lbf.in |
| 7. Wire range | 16AWG-26AWG |
| 8. Housing Material | PBT UL94V-0 |
| 9. Screw | Steel |
| 10. Contact | Brass |
| 11. Spring | SUS301 |
