Textile Industry Cobalt Chrome Alloy Cutter Blade Abrasion Resistant
What is the Details of our Cobalt Chrome Alloy bushings and sleeve ?
| Material : |
Cobalt Chrome Alloy |
| Process : | Powder Metallurgy , it is short for PM |
| Hardness: | 41-50 HRC |
| Density : | 8.3 g/cm ³ |
| Size : |
100-220mm length , width 30-60mm , thickness 1.15-4mm
|
| Properties : | Wear and corrosion resistance, high temperature resistance |
| Application : | Cutting staple fibre |
| Instructions : | Drawing made upon cutomers request |
| Sharpening surface : | available |
| Tolerance control : | grinding surface , tolerance upon drawing |
| Production lead time | Samples 10 days , normal order 15-25 days |
| Production capacity : | 30,000pcs one month. |
| Package : | carton or wooden case , pallet for export |
Chemical compositions and properties (%)
| COBALT ALLOY | C | Mn | Si | Cr | Ni | Mo | W | Co |
Cu
|
Others | Density | Hardness |
|
Fibre cutter blade
|
1.6-2.2 | 1.0 | 1.0 | 26-31 | 4.0-8.0 | 1.0-2.0 | 4.5-7.0 | Bal. | 0.5-2.0 | Nb 4.0-6.0 | 8.3g/cm³ |
45-50HRC |
The basic dimension that we have mould (L×W×T /mm):
175×39×4 mm
158×43×3mm
223.5×50×4mm
175×48×1.6mm
180×42×4mm
175×52×2mm
175×47×2.3mm
NOTE: We can accept customer made products , the new mould need 20 days to finish.
Simple Drawing
Application :
This kind of cutting blade fit for chemical fiber cutting industry , Light industry machinery and being running blades ,saw blade .It is famous of its outstanding corrosion resistance ,wear resistance and high temperature resistance . we exported it to many countries now , all the properties can be guaranteed.
Worldwide Market :
Our Service :
Controlling product 's quality strictly,serving fast,respecting contract,keeping credit and delivering in time.
1. High quality,lower price.
2. Customed production.
3. According to your application,we will recommend you the best material and hardness.
4. We can provide you with professional technical service and good after-sales service.
5. We custom blades according to your drawing or description .In order to provide prompt and accurate quotation , it's better that you can provide us the quantity,drawings,application and etc of products.
6. All of your inquiry and emails , we will give reply within 24 hours .
FAQ
Q1: What is the Warranty for our products ?
A1: We own high precision grading machine to control geometry dimensions and apply ultra fine grain size substrate coated with high performance coatings to guarantee the lifetime of our products, which can satisfy every working condition.If any quality problems on our side occurred in this period , we will take on the shipping cost and replacement.
Q2: Do you provide free samples?
A2: Yes, usually we provide free samples for testing under the condition of freight paid by customer.
Q3: What is your minimum order requirement?
A3: We will indicate the MOQ for each item in the quotation sheet. We accept the sample and trial order. If the quantity of single item can't reach the MOQ, the price should be sample price.
Q4: What is the delivery time of your products?
A4: It depends on the inventory availability.If items needed are in stock, the delivery time would be within 8 work days, but if not the delivery time would be around 20 work days.
Q5: Can you manufacture Special-shaped products?
A5: Yes, we can. We can produce both standard and special prosucts. We can make them according to your drawings and samples.
Q6: May I have my order working schedule ?
A6: Yes, we will send working schedule of your order each week. We will inspect and test all merchandise in case of damaging and missing parts before shipment. The detailed inspection pictures of the order will be sent to you for your confirmation before delivery.
Your feedback is our best honor, please do not hesitate to give us your valuable feedback and we can let you feel more confident to our company and products.
Send your inquiry right now .
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
