RF Drive Laser Scar Removal Machine Co2 Fractional , Acne Treatment Machine
2017new product! RF drive fractional co2 laser co2 fractional laser scar removal machine
Specifications
| Laser Type | 10.6μm |
| Output Power | W |
| Starting Voltage | kV |
| Operating Voltag | kV |
| Operating Current | mA |
| Focal length of working head | F=50mm |
| Indication Beam | Diode Laser(532nm, 5mW) |
| Transmission System | 7-Articulation Joint Spring Arm |
| Smoke Exhausting System | Built-in air blow |
| Cooling System | Water cooling |
| Environmental temperature | 5-40C |
| Power Supply | AC220V; 50Hz |
| Dimension | 430mm*350mm*1050mm |
| Weight | 25kg |
Working Mode
Continuos: Power 1~30W step adjustable each 1 W
Pulse: Power 1~30W step adjustable each 1
Interval time: 1~999ms
Ultra pulse: Power 1~30W step adjustable each 1
Modulated frequency of 1000 Hz
Pulse Duration: 90-1000μs
Product Description
Fractional resurfacing is a new laser treatment modality that creates numerous microscopic thermal injury zones of controlled width, depth, and density that are surrounded by a reservoir of spared epidermal and dermal tissue, allowing for rapid repair of laser-induced thermal injury. This unique modality, if implemented with proper laser-delivery systems, enables high-energy treatments while minimizing risks.
Indications
Skin resurfacing (to improve texture)
Pigmented lesions: Age spots / brown spots / sun spots
Wrinkles around the eyes
Acne scars
Surgical scars
Melasma (mask of pregnancy)
Actinic Keratoses
Scanning mode
Scan mode: Ellipse, Rectangular.
Scanning Range: 15*15mm
Repeat Delay: 0.1s---- 5.0s.
Micro Pulse Energy: 5mJ---50mJ.
Treatment Level: 0.30%-----25.0%.
Passes: 1-----10 times.
Estimated Power: 24mJ--1000J.
Ellipes estimated power: 31mJ----1000J
Rectangular estimated power: 24mJ----981J
Treatment area: 0.1*0.1mm, ----- 20*20mm.
Handpiece Velocity: 0.1-----9cm2/s
Scanning Depth: <1.8mm
