KVM Fiber Optic Hdmi Extender TCP IP CAT5E/6 Cable 1080P 60Hz
Price:
please contact seller
MOQ:
1
Delivery Time:
5-10 working days
Brand:
E-link
Product Description
120 Meter Extend Distance 1080P 60Hz HDMI KVM Extender Over TCP/IP CAT5E/6 cable
Features
- Aluminum shell, compact size and slim design, more beautiful than iron shell, strong anti-interference; Wall-mounted type is more convenient.
- Distance up to 120m over UTP CAT5E/6 cable.
- Video resolution max up to 1920*1080@60Hz.
- Support keyboard and mouse control .
- Have a local HDMI loop-out ;
- Support IR(38khz) signal pass back transmission .
- HDMI 1.3 and HDCP 1.2 standard.
- High compatibility, can auto-match source and display device.
- Built-in automatic adjustment system, make the image smooth, clear and stable.
- Built-in ESD protection system; Simple to install, plug and play.
- TCP/IP Ethernet communication.
- Real-Time Video/Audio Transmission over IP.
- Pure Ethernet , Simple Cabling .
- Ordinary 100M or 1000M Ethernet switch.
Technical Indexes
| Parameter | Description | |
| Video | Standards | HDMI 1.3; HDCP 1.2 |
| Maximum pixel clock | 165MHz | |
| Maximum data rate | 6.75Gbps | |
| Resolution | Max: 1920X1080@60Hz(backward-compatible) | |
| Connector | HDMI-A | |
| Impedance | 100Ω | |
| IR | Interface | 3.5mm earphone seat |
| Signal direction | Unidirectional | |
| Signal type | Digital | |
| IR frequency | 38kHz | |
| USB | Interface |
PC: Standard MINI-USB or PS2 K/M: Standard USB, PS2 (optional) |
| USB Signal | HID Signal | |
| Ethernet | Interface | RJ45(568B) |
| Transmission distance | UTP CAT5e/---120m | |
| Other | Power supply | The power adapter: DC 5V |
| Power dissipation | MAX 4W | |
| Temperature | Operating: -5℃ ~ +70℃ | |
| Humidity | Operating: 5% ~ 90% | |
| Dimension | 100*97.5*17mm | |
| The warranty | 1 year free warranty | |
Ordering Information
| Part No | Description of product |
| LNK-HDE-120KVM | 120M 1080P@60Hz HDMI KVM Extender Over TCP/IP |
