120m Extend HDMI Over Fiber Optic Extender 1080P 60Hz 165MHz With IR
Price:
please contact seller
MOQ:
1
Delivery Time:
5-10 working days
Brand:
E-link
Product Description
120 Meter Extend Distance 1080P 60Hz HDMI KVM Extender Over Network Cable with IR
Features
- Aluminum shell, compact size and Slim design, more beautiful than iron shell, strong anti-interference, Wall-mounted type
- Uncompressed and zero latency
- Auto adjustment to match the cable length
- The highest resolutions supported is up to 1080P@60Hz
- Extend HDMI signal over single UTP CAT6/6a/7 cable up to 60m
- Support EDID pass-through
- Only one power adapter is needed for the TX, the RX can be powered by the TX over network cable.
Technical Indexes
| Parameter | Description | |
| Video | Standards | HDMI 1.3; HDCP 1.2 |
| Maximum pixel clock | 165MHz | |
| Maximum data rate | 6.75Gbps | |
| Resolution | Max: 1920X1080@60Hz | |
| Connector | HDMI-A | |
| Impedance | 100Ω | |
| IR | Interface | 3.5mm earphone seat |
| Signal direction | Unidirectional | |
| Signal type | Digital | |
| IR frequency | 38kHz | |
| Ethernet | Interface | RJ45(568B) |
| Transmission distance | UTP CAT5e---120m | |
| Other | Power supply | The power adapter: DC 5V |
| Power dissipation | MAX 4W | |
| Temperature | Operating: -5℃ ~ +70℃ | |
| Humidity | Operating: 5% ~ 90% | |
| Dimension | 100*97.5*17mm | |
| The warranty | 1 year free warranty | |
Ordering Information
| Part No | Description of product |
| LNK-HDE-120 | HDMI Over CAT5/CAT6 Extender with IR - 395 ft (120m), including 1 Transmitter & 1 Receiver, used by pairs |
