Programmable Climate Test Walk-In Environmental Chamber for Material testing
Programmable Walk-In Environmental Chamber Climate Test
Programmable Climate Test Walk-In Environmental Chamber an economical and space-saving solution for a variety of testing requirements. It can simulate different climatic conditions, such as heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, which defines the performance of material. By testing the product under different climatic conditions to see whether its performance can meet the intended requirements. It is widely applied in the industries of electron, electrical equipment, vehicle, metal, food, chemistry, building materials, luggage, adhesion tape, printing, packaging, and other product components and materials.
| Model | SMC-080-CC-WT | SMC-120-CC-WT | SMC-160-CC-WT | SMC-250-CC-WT | SMC-340-CC-WT | SMC-400-CC-WT | |
| Temperature | Temperature control range | -65℃～80℃(+15℃)(A:0℃～80℃;B:-20℃～80℃；C:-40℃～80℃;D:-65℃～80℃) | |||||
| Temperature fluctuation | ±0.5℃ | ||||||
| Cooling rate | 80.0℃～-65.0℃ Within 110 mins 1.0～2.0℃/min | ||||||
| Heating rate | -65.0℃～80.0℃ Within 70 mins 2.0～5.0℃/min | ||||||
| Temperature uniformity | ±2.0℃ (-40.0℃～80.0℃) | ||||||
| ±2.5℃ (-40.0℃～-65.0℃) | |||||||
| Humidity | Humidity control range | 20.0%RH～95.0%RH | |||||
| Humidity fluctuation | ±1.5% RH | ||||||
| Humidity uniformity | ±3.0％RH | ||||||
| Material / components |
Internal material | Stainless steel(SUS304) | |||||
| External material | Cold rolled steel sheet / powder spraying | ||||||
| Heat insulating material | 100mm thickness polyurethane plate＋10mm thickness mineral wool | ||||||
| Fan | Centrifugal blower | ||||||
| Compressor | Semi-closed Germany Bock, Germany Bitzer | ||||||
| Condenser | Water-cooled | ||||||
| Refrigerant | R404A,R23,R508 | ||||||
| Evaporator | Fin - and - Tube Heat Exchanger | ||||||
| Heater | Nickel chromium alloy heating wire | ||||||
| Humidifier | Steam humidifier | ||||||
| Size | Interior size(mm) W*H*D |
1970*2100 *1970 |
3020*2100 *1970 |
4070*2100 *1970 |
3020*2100 *4070 |
4070*2100 *4070 |
5120*2100 *4070 |
| Outer size(mm) W*H*D |
2170*2350 *3500 |
3220*2350 *3500 |
4270*2350 *3500 |
4650*2350 *4270 |
5720*2350 *4270 |
5320*2350 *6150 |
|
| Volume(m³) | 8.0m³ | 12.0m³ | 16.0m³ | 25.0m³ | 34.0m³ | 40.0m³ | |
| Operating ambient temperature | +5 ~ 35℃ | ||||||
| Power supply | 380V AC 50/60Hz | 380V AC 50/60Hz | 380V AC 50/60Hz | 380V AC 50/60Hz | 380V AC 50/60Hz | 380V AC 50/60Hz | |
| Controller | Standard: South Korea TEMI-1500 Optional: South Korea TEMI-2500,South Korea TEMI-2700 | ||||||
