High Temperature Evacuated Tube Solar Hot Water Systems For Hospital
200L Colored Steel High Temperature Non Pressurized Vacuum Tube Solar Water Heater for Hospital
Description:
Non-pressure system is the most economic solar water heater which work stable and no need any maintenance.
It must be installed on the top, such as roof, to get enough hot water flow pressure.
Also The tank must be above the collector, so the thermosyphon phenomenon can occur, circulation water from collector to tank.
Feature:
Can be operated completely automatic if connect with intelligent controller.
Simple structure, easy plug-in installation, can be installed both on flat and inclined roof, and can be used with an auxiliary electric booster as to provide tot water without sunshine.
Superior heat preservation ensured by one-off molding polyurethane foam with thickness 55mm.
Suitable for camping area, holiday residences.
Stable and reliable performance, well wind resistance.
Meet the mankind healthy bath standard: The SUS304-2B material for inner tank; the long life silicon sealing ring against the erosion and not harmful to health.
| Model Name | SS solar water heater |
| Header pipe | SUS304-2B [0.65mm to 0.8mm] |
| Insulation layer | Polyurethane foam [55mm] |
| Manifold Casing | SUS304-2B [0.4mm] |
| Bracket | SUS201/304 [1.2mm] |
| Evacuated tube | Borosilicate Glass 3.3 |
SS serials is Thermosyphon solar water heater:
That is a kind of solar water heating system that solar collector and storage are connected together with the cylinder storage on the top and collector panel on the bottom.
There is no need of pump to push the fluid and no need of pipeline between the collector and storage.
It is a simple and safe solution to get heat power from the sun.
Advantage:
• The material of the outer tank is SUS304 2B stainless steel. The material of the inner tank is SUS304 2B stainless steel.
• The life of the vacuum tubes is 15 years.
• Stable and reliable performance, well resistance.
• Temperature when exposed to sun without water: 250°C, 2.5 hours to boiling point if using single tube.
• It resists 25mm hail.
• Heat preservation: 72 hours.
• Optional accessories: assistant tank, electric heater
• 6 years warranty.
Non Pressure Solar Water Heater-SS:
| Product Model | Tubes Qty. | LPD | Absorbing Area (m2) | Weight (KGS) | Dimension (L×W×H) |
| SS470-1800/58-12 | 12 | 120 | 0.92 | 52 | 1770*1050*1560 |
| SS470-1800/58-15 | 15 | 150 | 1.15 | 62 | 1770*1290*1560 |
| SS470-1800/58-18 | 18 | 180 | 1.37 | 72 | 1770*1530*1560 |
| SS470-1800/58-20 | 20 | 200 | 1.52 | 82 | 1770*1690*1560 |
| SS470-1800/58-24 | 24 | 240 | 1.83 | 95 | 1770*2010*1560 |
| SS470-1800/58-30 | 30 | 300 | 2.29 | 112 | 1770*2010*1560 |
Additional Terms:
| Payment Terms | L/C, T/T |
| Minimum Order | 2 sets |
| Lead Time / Delivery Time | 15 Day(s) |
| Sample Available | YES |
| Delivery Details | after receipt of payment |
| Port of Lading | Ningbo / Shanghai |
| Shipping | by sea |
| Packing | export carton |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Latin America, Southeast Asia |
