High Performance Flat Plate Solar Water Heater Pitched Flat Solar Collector
High Performance Flat Plate Solar Water Heater Pitched Flat Solar Collector
Features
1) Cover a window on heat pipe solar collector , has better appearance.
2) Reliable and efficient twin-glass solar tubes.
3) Copper heat pipes for rapid heat transfer.
4) Easy plug-in installation.
5) Free maintenance.
6) Work pressure: 8 bars.
7) Stable solar conversion during the day.
8) The perfect solar collector for domestic solar water heater systems.
9) Ideal for commercial solar water heating applications.
How it works:
1) Connect with pressure water tank and workstation. Water is circulated through the header via intermittent pump cycling. Each time the water circulates through the header , the temperature is raised by 5-10℃ . Throughout the day , the water in the tank is gradually heated.
2) Solar absorption : solar radiation is absorbed by the solar tubes and converted into heat.
3) Solar heat transfer:heat pipes conduct the heat from the solar tube up to the header pipe.
| Model Name | PT-F |
| Water production in sun day | 70~100kg/m2 |
| Water temperature in sun day | 50-90 centigrade degree |
| Maximum working pressure | 1.2Mpa |
| Absorption rate of heat-absorbing coating | 95% |
| Emissivity of heat-absorbing coating | 4% |
| Glass transmittance | >92% |
| Highest working temperature | 120-170 centigrade degree |
| Size of input and output | G3/4 |
| Material for heat-absorbing | TU1 |
| Material for water pipe | TU1 |
| Material for frame | Space aluminum-magnesium alloy |
| Color and artwork for frame | Completely closed (white,silver,bronze,green) |
| Useful life | 20 years |
| Product Model | Collector Qty. | Tank (L) | Absorbing Area (m2) | Weight (KGS) | Dimension (L*W*H) | Qty. per 20FT/40FT/40HQ |
| 100 | 1 | 100L | 2 | 52 | 1530*1100*1680 | 58 / 123 / 156 |
| 200 | 2 | 200L | 4 | 87 | 1530*1340*1680 | 34 / 75 / 93 |
| 300 | 3 | 300L | 6 | 127 | 1530*1580*1680 | 25 / 52 / 62 |
Additional Information
| Payment Terms | T/T, L/C |
| Minimum Order | One 20GP Container |
| Lead Time / Delivery Time | 15 Day(s) |
| Sample Available | YES |
| Delivery Details | One 40HQ within 15 days, ten 40HQ containers within 25 days, otherwise to be noticed |
| FOB Port | Shanghai |
| Packing Info | cartons with foam |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
FAQ
1- What is your Delivery Time?
LCL order/Sample order:10days.
Full container order:14days.
2- What is your Guarantee Time?
5 years.
Provide you with some extra accessories and vacuum tubes, they are free for you.
3- Can you accept OEM ?
YES
4- What is your Payment Term?
We accept T/T or L/C at sight, Western Union.
5- What is your MOQ?
1 sets
6- What is your Packing?
LCL order/Sample order in wood cartoon
Full container order in high quality export carton
7- What is your FOB Port?
We accept FOB Shanghai, Ningbo etc.
8.- What is your Monthly Production Capacity?
6000 sets
9- What is your Shipping Term?
By Sea/Air/Rail
