Split Pressurized Solar Water Heater Heat Pipe Collector For Large Capacity Solar Water Heating System For Hotel Resort
Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort
Capacity:
1000L/1500L/2000L/3000L/4000L/5000L.
Flat Plate Solar Water Heater Description:
Flat plate Solar Water Heater is one of common Solar Water Heater for solar water-heating system in homes and room heating.
Flat plate Solar Water Heater provide quality hot water with its new solar energy efficient flat plate design.
The flat plate solar collector includes a selective coating to maximize the solar heat absorption,
aluminum framing and interior fiberglass insulation for increased efficiency.
Advantage:
1. Highly efficient absorber of high performance with daily average efficiency over 76%;
2. Blue film absorber with automatic production line,can supply you stable high quality products;
3. Withstand pressure of 6 Bar, can be connected directly with city water or your big water tank;
4.Simple structure, easy to assembly and install in short time, no breakage;
5.Best insulation with polyurethane foam;
6.Can be used all year round in the cold climate;
7.Can be used together with auxiliary electric boost;
8.Long service life, can be used over 15 years;
Flat Plate Solar Water Heater Features:
1.Using patent advanced coating technology with high efficiency performance.
2. High strength aluminum-alloy structure with surface varnish baking
3. High visual shape ,easy installation ,maintenance free
4. Pressurized designing, operate with pressure up to 1 Mpa
5. Can be combined with existing energy source
Heat Pipe Solar Collector Technical Data:
| Model | PT-C-15 | PT-C-18 | PT-C-20 | PT-C-24 | PT-C-25 | PT-C-30 |
| Tube QTY(PCS) | 15 | 18 | 20 | 24 | 25 | 30 |
| Three Target Vacuum Tube | Diameter/Length: φ58mm/1800mm; High boron and silicon content 3.3; Structure:Gradual change SS-AL-Nx/Cu selective absorption coating; Vacuum Degree:P<=5*10-3; | |||||
| Heat Pipe | Condesor: φ14/φ24*70mm ; Thickness: 0.5mm ; Material: red copper TU1+water; Transfer Power:>=150W; Working Pressure:4Mpa; Welding Pressure:4Mpa; | |||||
| Outer Shell/Bracket | Alluminum Alloy,Silver | |||||
| Insulation Layer | Rock wool | |||||
| Dustproof Rubber | EPDM | |||||
| Dsily Heat Gain | 8.5MJ/m² | |||||
| Work Pressure | 0.6MPa | |||||
| Inlet/outlet | 22mm/3/4" | |||||
| Tailstock | ABS | |||||
| Temperature | 250 °С | |||||
| Contour Aperture Area | 2.32m² | 2.75m² | 3.10m² | 3.64m² | 3.78m² | 4.52m² |
| Aperture Area | 1.43m² | 1.70m² | 1.89m² | 2.27m² | 2.36m² | 2.83m² |
| Absorption Area | 1.22m² | 1.46m² | 1.62m² | 1.95m² | 2.04m² | 2.43m² |
Packing:
LCL( Less than Container Load ):Wooden case
FCL( Full Container Load ):Export carton
Delivery:
Usually, it is 10 Working days after receiving deposit or original L/C.
