Solar Water Heater Accessories New Brass Adjustable Water Thermostatic Mixing Valve

Technology parameters:

Mixed water temperature range:35----60℃

set temperature:55℃

Mixed water temperature accuracy:±2℃

Hot water temperature range:55-100℃

Cold water temperature range:5-25℃

Cold water, hot water working pressure range: 0.5--5bar

Maximum allowable allows the static pressure:16bar

Maximum flow:40L/min

Specification: DN15,DN20

Product standards:EN1111,AS4032

Mixing valve materail:HPb59-1;

Piston material:PPO

Spring material:stainless steel304;

Sealing pieces of material:EPDM

Handle Material:ABS

Surface treatment:Sandblasted nickel-plated;

Installation

Before installing the mixing valve,cleaning of the system and make sure no Impurities in it;

In order to make the mixing valve working normally, It should be installed according to the drawing as follow; hot water pipe must connect with A section marked with an "H" and cold water pipe must connect with A section marked with an "C"; Mixing pipe can connect with A section marked with an "MIX"; Mixing valve can be installed Horizontal and vertical installation
