Cast Hydraulic Press Block Pallet Transfer Carts , Automated Die Handling Equipment
Cast Hydraulic Press Block Pallet Transfer Carts with Steel Frame
Product Introduction---50 ton Automated Die Handling Equipment
The automated die handling equipment is powered by the battery. It is used for transporting die, heavy material or metal parts to cross the curved path and staight steel square bar. The curved rail can be arc shape or S shape, the turning radius is decided by the length of the handling equipment and your actual demand. This kind of automated die handling equipment has been widely applied in these fields, such as construction, steel plant, shipyard, foundry plant etc. It also can be combined with other function, such as lifting, tilting, weighting system etc.
Application Sites---50 ton Automated Die Handling Equipment
The automated die handling equipment is mainly applied in assembly line(ring production line,loop production line),metallurgy industry(steel lade),warehouse transport,ship industry(maintenance, assemcle,container transport),work piece transport in workshop,lathe transport,steel factory(steel billet,steel plate,steel coil,steel pipe,section steel structure),construction(bridge,simple building,concrete column,)petroleum industry(oil pump,sucker rod and parts),energy(polycrystalline silicon,generator,windmill),chemical industry(electrolytic cell,retort etc),railway(rail maintenance,rail welding,train tractor).
Parameter Table---50 ton Automated Die Handling Equipment
| Specification of Automated Die Handling Equipment | |
|---|---|
| Load capacity(T) | 1-300 |
| Table Size(mm) | Standard in 5500*2500*650/ Customized |
| Runing Speed(m/min) | 0-25 |
| Power Feeding Mode | Storage Battery |
| Turning radius | Decide by the length of the handling equipment |
| Recommend rail type | P38 or 40# square bar |
| Motor Power(Kw) | 5 |
| Max wheel load(KN) | 174 |
| Reference Weight(T) | 8 |
| Wheel dia(mm) | 500 |
| Rail Inner Gauge | 1435/Customized |
Why Choose Us?
We have a professional sales team,can privede you a quick and professional reply.
16 hours engineering service and 24 hours internet service for our customers
12 Months warranty for whole machines, providing all parts free of charge
we can produce the largest tonnage material transfer cart, just give us your demand
The transfer cart is easy for operation, don't worry about how to handle
Products are sold to Europe, North America, South America, Middle East etc
Inquiry Tips
1. The Load Capacity (t)?
2. The Dimension (Length, Width, Height)?
3. The running Speed (m/min)?
4. The running distance?
5. The usage of the transfer cart?
6. The type of the power mode supply (battery, cable, diesel)?
