Rail Electric Flat Car / Battery Transfer Cart 1- 300 Ton Load Capacity
Curved Rails Moving Cart Automated Guided Vehicles China Rail Electric Flat Car
Product Preview of Automated Guided Vehicles
You can operate our Automated Guided Vehicles on rails. It's special designed and powered by storaged battery. We have mounted on special control syatem in it, so you can control it by pendant or remote control. We can also accept customization and mount on special used devices for you as per your request. For example, you can fit lifting, warning light, buffer and many other devices. We can provide you with flat car from 1 to 300 ton. We are sure to provide satisfied products for you!
Application Fields of Automated Guided Vehicles
We have been working in this line for over 15 years. Our main products include material transfer carts, coils and pipes transport trolleys, industrial trailers, factory transport equipment, electric warehouse carriages, ladle carts, motorized battery operated transfer vehicle and so on. According to your demands, we can assure that you will be satisfied with our product and service. So if you are interested in our products, don't hesitate and tell us your plann as soon as possible. We are always pursuing to provide the highest quality and service for you!
Parameters of Automated Guided Vehicles
| Model | BXC-2t | BXC-20t | BXC-50t | BXC-100t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | |
| Table Size (mm) | Length(L) | 2000 | 4000 | 5500 | 6500 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | |
| Height(H) | 450 | 550 | 650 | 900 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 200 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | |
| Motor Power(kw) | 1 | 2.2 | 5 | 10 | |
| Battery Capacity | 180 | 180 | 330 | 440 | |
| Battery Voltage | 24 | 48 | 48 | 72 | |
| Running Time When Full Load | 4.32 | 4 | 3.3 | 3.2 | |
| Running Distance for One Charge(Km) | 6.5 | 4.8 | 4 | 3.8 | |
| Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | |
| Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | |
Packing and Shipment Automated Guided Vehicles
According the table size and quantity, the cart would be carefully fixed and transported by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.
Wanna Find Us?
Help you to choose the most suitable cart
Thank you very much for looking through the information above. If you are interested in our products, please send us an E-mail and tell us the following information. Thank you!
- What material/cargo are you going to transfer?
- What load capacity do you want?
- What kind of ground does the transfer cart operate on? (rails or cement floor)
- What’s the specification table size ? (length,width and height)
- How long is the running distance?
- How many working hours do you have everyday?
- What special requirements do you have?
