transport steel billet industrial battery transfer trolley
transport steel billet industrial battery transfer trolley
The industrial battery transfer trolley is specially designed to transfer the high-temperature metal ladle, molten steel, boiler, molten slag and scrap steel. The industrial battery transfer trolley materials, driving system and electrical control should be specially designed. The tractor motor of the industrial battery transfer trolley is designed in slowly start and stop to reduce the inertia of the car and avoid molten steel or slag from splashing. The heat insulating material is used in the industrial battery transfer trolley to resist the high temperature. Usually the Industry trolley cart is preparing two motors. So when one is damaged by the Ladles' temperature the other can be used to continue work. The industrial battery transfer trolley is available in inflammable and explosive environment. The industrial battery transfer trolley can be powered by cable or battery and can equipped with load meter.
| Model | 2t | 20t | 50t | 100t | 150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Heigth(H) | 450 | 550 | 650 | 900 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 2.2 | 5 | 10 | 15 | |
| Running time When Full Load | 4.32 | 4 | 3.3 | 3.2 | 2.9 | |
| Running Distance for Once Charge(KM) | 6.5 | 4.8 | 4 | 3.8 | 3.2 | |
| Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | 26.8 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
- With forward or backing driving;
- Options for automatic control;
- Payload from 1 ton to 300 tons;
- Fixed speed or variable speed capabilities;
- The Industry trolley cart is Anti-high temperature, Anti-high explosion;
- The Industry trolley cart can run on the C-form track or S-form track and L-form track;
- The Industry trolley cart can be powered by battery,low voltage rail,trailing cable,cable drum;
- Available safety equipment includes horn, lights, emergency stop, bumpers and detector;
- Safe and convenient operation is available for this Industry trolley cart .
