industrial electric transport flat cars for transfer steel coil
Price:
USD 3000~7500 set
MOQ:
1 set
Delivery Time:
20 work days after received balance payment
Brand:
industrial electric transport flat cars
Product Description
industrial electric transport flat cars for transfer steel coil
Henan Perfect Handling Equipment Co., Ltd covers an area of 30,000 aquare meters and output is 500sets motorized Ladle Trolley.Our Ladle Trolley have been sold to every city in China and exported to almost 20 countries,such as Germany,Turkey,South Africa,Thaniland and so on.Ladle Trolley Ladle Trolley adle Trolley Ladle Trolle
This BDG-Ladle Trolley is powered by the rails.The rails need to be insulated in erection.When the running distance is longer than 70m , the transformer needs to be increased to raise the voltage.L
Technical Parameters Of industrial electric transport flat cars
| Model | BDGS-2t | BDGS-20t | BDGS-50t | BDGS-100t | BDGS-150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Heigth(H) | 450 | 550 | 650 | 850 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 0.8 | 2.5 | 5.5 | 11 | 15 | |
| Transformer Power(KVA) | 3 | 6.8 | 10 | 30 | 30 | |
| Transformer Quanity | 1 | 1 | 1 | 1 | 1 | |
| Running Distance(m) | 70 | 70 | 50 | 50 | 50 | |
| Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | 265.2 | |
| Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | 26.8 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
Packing & Deliverry Of Ladle Trolley
