Electric Heavy load battery motorized industrial material trackless transfer cart with Wireless Control
Electric Heavy load battery motorized industrial material trackless transfer cart with Wireless Control
The trackless Material Transfer Cart is battery powered with wireless remote control, motor gear reducer as driving system, solid PU wheels can be run on the ground directly and flexibly with no limited running distance. And imported solid PU wheels can reduce the impair for the ground. The Electric Heavy load battery motorized industrial material trackless transfer cart with Wireless Control can be suitable for smaller space by 360 degree spot turning, 360 degree protection to guarantee site safety, including dead man stop, emergency stop., anti-collision device... touch-screen, Pry bar device,...this design is humanization and modernization. Automated operation makes the car more intelligent.
Functions of Electric Heavy load battery motorized industrial material trackless transfer cart with Wireless Control
1.The Sound&light alarm is installed on the Material Transfer cart.
2.The lifting hole are installed on the wireless remote control flat car for convenient transporting.
3.The intelligent charger is chosen to export, it has high frequency, little interference to the grid, and small volume.
4.Convenient, and long lifetime.
5.The car frame is two longitudinal beam, several beams with steel panel welded together.
6.The power supply are chosen as per your working environment.
Detailed Image of Electric Heavy load battery motorized industrial material trackless transfer cart with Wireless Control
Technical parameter table of Electric Heavy load battery motorized industrial material trackless transfer cart with Wireless Control
| Rated Load(T) | 5 | 10 | 15 | 20 | 30 | 40 | 50 |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Wheel Base(mm) | 1500 | 1500 | 1500 | 1700 | 1700 | 1800 | 1800 |
| Turnning Radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 |
| Axles Distance(mm) | 2500 | 3100 | 3400 | 3900 | 4300 | 4800 | 5200 |
| Motor Power(Kw) | 3.5 | 5 | 6 | 7 | 10 | 12 | 15 |
| Running Speed(m/min) | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-12 | 0-12 |
| Cart Weight(t) | 4.3 | 5.3 | 6.6 | 7.9 | 8.8 | 10 | 10.5 |
| Impacted Rated Load(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 |
| Battery Capacity(Ah) | 180 | 160 | 180 | 180 | 250 | 300 | 330 |
| Battery Voltage(v) | 36 | 48 | 48 | 48 | 48 | 48 | 48 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 44 | 4 | 4 |
| Ground Requirement | Cement Floor | Cement Floor | Cement Floor | Cement Floor | Cement Floor | Cement Floor | Cement Floor |
Application of Electric Heavy load battery motorized industrial material trackless transfer cart with Wireless Control
The wireless remote control flat car can be used in all kinds of environment with no limited running distance.The Electric Heavy load battery motorized industrial material trackless transfer cart with Wireless Control's application range includes: mold field, car field, steel, iron, heavy industry, light industry, chemical, mine, ship, project, spaceflight, coal, nuclear energy, hydraulic engineering, etc. etc.
For material transport: mould, boiler, coil items, transformer, shaft, drum, steel ladle, steel structure, steel pipe, mould, beam, container, heavy equipment, Aluminum product, compressor, polycrystalline silicon, motor, coil, scrap, pallet...
