5.0mm 3D Wire Wire Fence Panels Panels Metal Border Fencing Weather Resistance
5.0mm 3D Wire Fence Panels Metal Border Fencing Weather Resistance
Product Description
It is made of hot-dip galvanized wire or PVC-coated wire. These hexagonal wire meshes are mainly used for garden fencing, climbing plant support, rabbit netting, chicken netting, birdcages, Etc, due to their excellent corrosion resistance, high strength, and sturdy construction.
Type: Garden Fencing
Place of Origin: Hebei, China
Frame Material: Metal
Metal Type: Steel
Surface Treatment Type: Heat Treated
Finishing: PVC Coated,Powder Coated. Electric/Hot dipped galvanized.
Item: weld wire fence
Material: high quality low carbon steel wire/tube
Wire diameter:3-6mm
Mesh Aperture:50*100mm,50*150mm,50*200mm,100*100mm,100*200mm,etc
Height: 1.03m,1.23m,1.53m,1.83m,2.03m,2.23m,etc
Width:From 1000mm to 3000mm
Color:RAL6005,RAL9005,RAL9010,other color can make as your interesting.
Post: Square post:50*50,60*60,80*80,40*80mm,100*100mm;Round post:48,60,75mm,Peach post:70*100mm,etc
Fence post thickness:1.0-5.0mm
Product Specification
| Specification of Welded Wire Mesh | ||||
| Opening | Wire Diameter | Width
0.4-2M
Length 5-50m |
electric galvanized before welded,
electric galvanized after welded, hot-dipped galvanized before welded, hot-dipped galvanized after welded, PVC coated, Stainless steel wire |
|
| In inch | In metric unit | |||
| 1/4″ x 1/4″ | 6.4 x 6.4mm | BWG24-22 | ||
| 3/8″ x 3/8″ | 10.6x 10.6mm | BWG22-19 | ||
| 1/2″ x 1/2″ | 12.7 x 12.7mm | BWG23-16 | ||
| 5/8″ x 5/8″ | 16x 16mm | BWG21-18 | ||
| 3/4″ x 3/4″ | 19.1 x 19.1mm | BWG21-16 | ||
| 1″ x 1/2″ | 25.4x 12.7mm | BWG21-16 | ||
| 1-1/2″ x 1-1/2″ | 38 x 38mm | BWG19-14 | ||
| 1″ x 2″ | 25.4 x 50.8mm | BWG16-14 | ||
| 2″ x 2″ | 50.8 x 50.8mm | BWG15-12 | ||
| 2” x 4″ | 50.8 x 101.6mm | BWG15-12 | ||
| 4” x 4″ | 101.6 x 101.6mm | BWG15-12 | ||
| 4” x 6″ | 101.6 x 152.4mm | BWG15-12 | ||
| 6” x 6″ | 152.4 x 152.4mm | BWG15-12 | ||
| 6” x 8″ | 152.4 x 203.2mm | BWG14-12 | ||
| Note: Special specifications can be made according to customers requires. | ||||
| Wire Dia | Mesh Size | Panel Width | Panel Height | Folds | Post Height | Post Model | |
| burying style | bass style | ||||||
| 3.0mm; 4.0mm; 5.0mm; 6.0mm |
50*100mm; 50*200mm; 50*150mm; 70*150mm |
1-2.5m | 1.03m | 2 | 1.4m | 1.2m | Square; Peach; Round |
| 1.23m | 2 | 1.6m | 1.4m | ||||
| 1.53m | 3 | 2.0m | 1.7m | ||||
| 1.73m | 3 | 2.2m | 1.9m | ||||
| 1.83m | 4 | 2.3m | 2.0m | ||||
| 2.03m | 4 | 2.5m | 2.2m | ||||
| Color | RAL6005,RAL9005,RAL9010,other color can make as your interesting | ||||||
Product Process
| 1. | Black wire→Welding→Hot dipped galvanized→Powder coated/PVC coated |
| 2. | Black wire→Hot dipped galvanized→Welding→Powder coated/PVC coated |
| 3. | Black wire →Welding→Electric galvanized→Powder coated/PVC coated |
| 4. | Black wire→Electric galvanized→Welding→Powder coated/PVC coated |
Product Features
This style Fence panel using high quality low carbon steel wire welded .The fence surface after PVCor power coating will be brightness and comfortable ,it has highability to resist corrosive and unltraviolet.
Product Application
1 Construction
2 Garden Fencing
