Ridge Cap Roof Tile Roll Forming Machine / Metal Roof Profile Camber
Metal Roof Profile Camber Ridge Cap Roof Tile Roll Forming Machine
Machine components
| No. | Name | Qty |
| 1. | De-coiler | 1 Set |
| 2. | Roll Forming Machine | 1 Set |
| 3. | Hydraulic Pressing and Cutting Device | 1 Set |
| 4. | PLC Control Box | 1 Set |
| 5. | Hydraulic Pump | 1 Set |
| 6. | Output table | 1 Set |
Parameter
Metal ridge cap machine Parameters:
| NO | Name | Specification | |
| 1. | Decoiler | Weight capacity | PPGI steel |
| Coil Width | 305mm | ||
| Inner Diameter | 470-530mm | ||
| 2. | Film covering | Width | 305mm |
| 3. | Forming Machine | Roller station | 14Rows |
| Diameter of shaft | 70mm | ||
| Material of rollers | 45#Steel | ||
| Technology of rollers | Quench to increase the hardness | ||
| Surface of rollers | Plate hard Chrome 0.05mm | ||
| Main bearing | 6210 /bearing steel | ||
| Frame | 300MmC-Beam | ||
| Middle plate thickness | 16mm | ||
| Chain | 1inch | ||
|
4. |
Cut Off |
Operation | Automatic hydraulic type |
| Material of blade | CR12 steel | ||
| Oil pressure station | Motor,oil pump,electromagnetic valve etc. | ||
| Motor of oil pressure station | 3KW | ||
| Working pressure | 0-14MPA | ||
|
5 |
Automatic stacker
|
Size | 6Meters |
| Type | Automatic Side Roll-out | ||
| Main motor | 5.5KW | ||
| voltage | 480V 60HZ | ||
|
6. |
Electric Box With touch screen |
Data input | imperial system (inches and decimals) |
| PLC control system | Delta Brand | ||
| Frequency converter | Delta Brand | ||
| Counter | Omron | ||
| 7. | Language | English | |
| 8. | Length of line | 10Meters | |
| 9. | Speed |
4M/Minute |
|
ELECTRONIC CONTROL SYSTEM
(1)Type: PLC Frequency Control System with touch screen
(2) PLC Brand: Deta
(3) Encoder Brand: Omron
(4)Length Error: ±2mm
(5)Language: English and Chinese
(6)Voltage: 380v/50HZ, 3Phase (it depends on customer requirement)
