20m Water Tower Fire Truck 6 Ton Imported Chassis 6x4 Fire Engine Vehicle
20m working height Water 6ton imported chassis 6X4 water tower fire truck 28ton Foam 4ton
Waterway operation panel
At the top of pump room trail.
Alarm lamp and stroboscope lamp
In front of the vehicle roof equipped with TBD035181 long row alarm lamp, LTE595 stroboscope lamp on both side.
Controller
Finland EPEC2024 imported with original packaging
Remote Control
Italian AUTEC wireless remote controller imported with original packaging, effective working radius 100m.
Fire fighting performance
| Spray flow/pressure | 4200L/min @ 1.6MPa |
| Spray range(water/ foam) | ≥70/65m |
| Foam proportioner | 6% (manual adjustment) |
Liquid tank
| Manufacturer | Shanghai Jindun special vehicle equipment Co., Ltd |
| Capacity | Water: 6000kg Foam: 4000kg |
| Material | High quality 304 stainless steel |
| Structure | Welded frame, shock-reducing support |
| Equipment |
2 manholes 2 fluid level gauges 2 drain outlets with stainless steel ball valve 1 outside suction port, 1 inside filling pipe end 4 outside filling ports |
|
Vehicle
|
Dimension (L×W×H) | 10970×2480×3900 (mm) |
| Chassis brand | Mercedes Benz | |
| Seat (inc. driver) | 2+4 seats (4 doors) | |
| Max. power | 320KW | |
|
Chassis
|
Manufacturer | Germany Mercedes Benz |
| Model | Actros3344 | |
| Driving | 6×4 | |
| Cabin | 1+1+4 | |
| Wheel base | 4500+1350 (mm) | |
| Curb weight | 14550Kg | |
| Full loading weight | 28000Kg | |
| Max. running speed | 100Km/h | |
| Engine type | V type six-cylinder, inter-cooling, electronic unit pump diesel engine | |
| Model | OM501LA.IV/4 | |
| Engine power | 320Kw/1800rpm | |
| Maximum torque | 2100N.M | |
| Emission standard | EURO IV | |
| Clutch | Monolithic, dry | |
| Gearbox | Manual-automatic |
Shanghai Jindun special vehicle Equipment Co., Ltd. is a high-tech special vehicle enterprise and flagship company of jindun group. It owns first class factory, internationally advanced processing equipment, gathers many top technicians and industrial experts, establishes national grade technology R&D center, and has 112 types of products, including truck crane, aerial working platform truck, road wrecker truck, road maintenance truck, dump truck, CAFS fire trucks, chenical fire truck, water tank foam trucks, emergency rescue vehicles, gas supply vehicles, lighting truck, satellite communication command vehicle, road-rail convertible vehicle, aerial ladder trucks, aerial platform truck, airport fire trucks, long distance water supply truck, water tower fire truck and other general fire trucks.
