Max Power 320KW 6x4 Drive High Spray Water Tower Fire Truck 20m Working Height
Price:
Negotiable
MOQ:
1 unit
Delivery Time:
90 days after sign contract
Brand:
CIMC Jindun
Product Description
Max Power 320KW 6x4 Drive High Spray Water Tower Fire Truck 20m Working Height
Main specification
|
Vehicle
|
Dimension (L×W×H) | 10970×2480×3900 (mm) |
| Chassis brand | Mercedes Benz | |
| Seat (inc. driver) | 2+4 seats (4 doors) | |
| Max. power | 320KW | |
|
Chassis
|
Manufacturer | Germany Mercedes Benz |
| Model | Actros3344 | |
| Driving | 6×4 | |
| Cabin | 1+1+4 | |
| Wheel base | 4500+1350 (mm) | |
| Curb weight | 14550Kg | |
| Full loading weight | 28000Kg | |
| Max. running speed | 100Km/h | |
| Engine type | V type six-cylinder, inter-cooling, electronic unit pump diesel engine | |
| Model | OM501LA.IV/4 | |
| Engine power | 320Kw/1800rpm | |
| Maximum torque | 2100N.M | |
| Emission standard | EURO IV | |
| Clutch | Monolithic, dry | |
| Gearbox | Manual-automatic |
Fire pump
| Model | CB10/100-ZX CHINESE FIRE PUMP |
| Flow rate | 6000L/min(1.0MPa), 4200L/min(1.6MPa) |
| Water diversion | Four pistons water diversion device |
| Seal | Mechanical seal |
Boom structure
| 2 folding boom, welded with high-strength steel | |
| Max. working height | 20m |
| Max. working radius | 9m |
| Pump flow | 100L/s |
| Boom extending time | ≤60s |
| Outrigger extending time | ≤35s |
| Hydraulic system pressure | 20MPa |
| Max. wind velocity | 12.5m/s |
| Outrigger longitudinal and transverse | 5200×2070mm |
| Allowed working range: Shown as pic1 | |
Controller
Finland EPEC2024 imported with original packaging.
Remote Control
Italian AUTEC wireless remote controller imported with original packaging, effective working radius 100m.
