FAW CA5115JQZ 8 Ton Hydraulic Truck Crane , Boom 7～17.25m Length
Price:
USD
MOQ:
1
Delivery Time:
3months
Brand:
Jiefang
Product Description
Max Rated lifting weight 8Ton hydraulic Truck crane 7～17.25m Length of main boom
One. Working Condition
1,Altitude: 0-4500m
2,Temperature: -25℃--+45℃
3,Allowed working condition: solid, stable land, the vehicle should be horizontal
4,Wind force: ≤6 degree
Two. Standard Equipments
1. FAW CA5115JQZ
2. Main boom assembly
3. Vice boom assembly
4. Hanging hook assembly
5. Windlass assembly
6. Slewing system
7. Electric system
8. Hydraulic system
9. Outrigger
10. Superstructure control system
11. Chassis control system
12. Tool box
Three. Main Parameters
| Items | Unit | Value | |
| Working Performance Parameters | Max. Rated lifting weight | kg | 8000 |
| Max. Lifting force of the basic boom | kn.m | 245 | |
| Max. Lifting force of the longest main boom | kn.m | 108 | |
| Max. Height of the basic boom | m | 7.95 | |
| Max. Height of the main boom | m | 17.95 | |
| Max. Height of the vice boom | m | 23.7 | |
| Max. Speed of the single rope | m/min | 120 | |
| Working Speed | Extension time of the lift boom | s | 30 |
| Lifting time of the lift boom | s | 25 | |
| Turning speed | r/min | 0～2.5 | |
| Traveling Parameters | Max. Traveling speed | km/h | 74 |
| Max. Grade ability | % | 30 | |
| Min. Turning radius | m | 8.2 | |
| Min. Ground clearance | m | 0.265 | |
| The whole weight | kg | 11400 | |
|
Dimension Parameters |
External dimension(length×width×height) | mm | 8480×2400×3110 |
| Vertical span of outrigger | m | 3.86 | |
| Horizontal span of outrigger | m | 4.2 | |
| Length of main boom | m | 7～17.25 | |
| Length of vice boom | m | 6 | |
| Elevation of main boom | ° | -2～75 | |
