XICHAI CA4DF3-13E3 Engine Hydraulic Truck Crane 101kw , 25℃--+45℃

Price Negotiable

Price: USD

MOQ: 1

Delivery Time: 3months

Brand: Jiefang

Product Description

7～17.25m Length of main boom hydraulic Truck crane Max Rated lifting weight 8 Ton

One. Working Condition

1,Altitude: 0-4500m

2,Temperature: -25℃--+45℃

3,Allowed working condition: solid, stable land, the vehicle should be horizontal

4,Wind force: ≤6 degree

Two. Main Parameters

Items		Unit	Value
Working Performance Parameters	Max. Rated lifting weight	kg	8000
	Max. Lifting force of the basic boom	kn.m	245
	Max. Lifting force of the longest main boom	kn.m	108
	Max. Height of the basic boom	m	7.95
	Max. Height of the main boom	m	17.95
	Max. Height of the vice boom	m	23.7
	Max. Speed of the single rope	m/min	120
Working Speed	Extension time of the lift boom	s	30
	Lifting time of the lift boom	s	25
	Turning speed	r/min	0～2.5
Traveling Parameters	Max. Traveling speed	km/h	74
	Max. Grade ability	%	30
	Min. Turning radius	m	8.2
	Min. Ground clearance	m	0.265
	The whole weight	kg	11400
Chassis	Model	—	CA5115JQZ
	Engine model	—	XICHAI CA4DF3-13E3
	Rated power/rotate speed	kw/(r/min)	101/2500
	Max. Torque/rotate speed	n.m/(r/min)	450/1400
	Axle base	mm	4050
