Altitude 0 - 4500m Kaifan Hydraulic Truck Crane 70km / H 11 Degree Departure Angle
Price:
USD
MOQ:
1
Delivery Time:
3months
Brand:
KaiFan
Product Description
Turning speed 0～2r/min 70km/h speed KaiFan Brand 25T truck Crane Lifting weight 25000kg
Two. Working Range
“KAI FAN” Brand KFM5323JQZ25G5(QY25G5)Crane is fully hydraulic telescopic crane, the maximum rated lifting capacity is 25t. It can be applied in various conditions for lifting and installation work, such as industrial and mining establishments, building site, station, sea port, warehouse and so on.
One. Working Condition
1,Altitude: 0-4500m
2,Temperature: -25℃--+45℃
3,Allowed working condition: solid, stable land, the vehicle should be horizontal
4,Wind force: ≤6 degree
Three. Main Parameters
| Items | Unit | Value | |
| Working Speed | Extension time of the lift boom | s | 110 |
| Lifting time of the lift boom | s | 60 | |
| Turning speed | r/min | 0～2 | |
| Weight Parameters | The whole weight | kg | 31670 |
| Load of the front axle | kg | 6850 | |
| Load of the rear axle (duel axle) | kg | 24820 | |
| Traveling Parameters | Max. Traveling speed | km/h | 70 |
| Max. Grade ability | % | 30 | |
| Min. Turning radius | m | 11 | |
| Min. Ground clearance | m | 0.27 | |
| Approaching angle | ° | 16 | |
| Departure angle | ° | 11 | |
|
Dimension Parameters |
External dimension(length×width×height) | mm | 12790×2500×3460 |
| Vertical span of outrigger | m | 5.35 | |
| Horizontal span of outrigger | m | 6.1 | |
| Length of main boom | m | 10.3~39.5 | |
| Length of vice boom | m | 8.3 | |
| Elevation of boom | ° | -2~80 | |
| Chassis | Model | — | TAZ5323J |
| Engine model | — | WP10.270 | |
| Rated power/speed | kW/(r/min) | 199/2200 | |
| Max. Torque/rotate speed | N.m/(r/min) | 1100/1200-1600 | |
