H Series 8x4 Drive Heavy Duty Road Wrecker Truck Max Hanging Weight 25000KG
Price:
Factory price. Negotiable
MOQ:
1 unit
Delivery Time:
90 days after sign contract
Brand:
KaiFan
Product Description
Three seats H Series 8x4 Drive Heavy Duty Road Wrecker Truck Max Hanging Weight 25000KG
A,Working Condition for road wrecker
1,Altitude: 0-4500m
2,Temperature: -35℃--+45℃
3,Relative humidity: 80%
4,Wind force: ≤8degree
B,Working Range for road wrecker
KFM5442TQZ Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind
C,Main Parameters for heavy duty road wrecker
| Items | Unit | Value | |
| Lifting Structure | Rated Lifting weight | kg | 13765 |
| Max. Lifting weight of original place | kg | 18000 | |
| Max. Lifting weight of full extension boom | kg | 8000 | |
| Rated towing weight | kg | 44000 | |
| Max. Designed towing weight | kg | 60000 | |
| Effective length of boom | mm | 3350 | |
| Extension traveling of boom | mm | 1700 | |
| Folding angle of boom | ° | 90 | |
| Under lift Structure | Max. Rated hanging weight | kg | 25000 |
| The height from hook to the ground | mm | 13430 | |
| Max. Extension traveling of lifting boom | mm | 6000 | |
| Rotation angle | ° | 360 | |
| Numbers of winch | piece | 2 | |
| Rated pulling power of winch | kg | 2×15000 | |
| Dia. Of steel cable | mm | 22.4 | |
| Length of steel cable | m | 40 | |
| Min. Speed of steel cable | m/min | 4 | |
| Rotation angle | ° | 65 | |
|
Vehicle Parameters |
External dimension | mm | 10741×2500×3366 |
| Chassis model | FM400 84RB | ||
| Drive | 8×4 | ||
| Axle base | mm | 1995+4405+1370 | |
| The whole weight of empty load | kg | 30040 | |
| Load of front axle of empty load | kg | 14380 | |
| Load of rear axle of empty load | kg | 15660 | |
| The whole weight of full load | kg | 44000 | |
| Load of front axle of full load | kg | 9000/9000 | |
| Load of rear axle of full load | kg | 13000/13000 | |
| Wheel base (front/rear axle) | mm | 2019/1834 | |
FAQ
| 1, Q: Why should we choose you ? |
| A: We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting. |
| B: We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur |
| C: We have our own R&D team, production workshop, QC management team, international marketing team and after service team. |
| D: We will provide the most professional and the best service on every business discussion and operation procedure. |
| E: We can provide special design for different specification requirement according to different orders or tender documents. |
| G: We have jointed ventures with Morita for 4 years, so the technology, design and quality are same with Morita. |
| H: We have collaboration with various top enterprises of fire protection sector, Such as Darley, Rosenbauer, HALE, AKRON, Ekhart, etc. |
| I: Our Certifications: ISO, TUV, CCCF, SONCAP, CNAS, SGS,MH /T5002-9, MEP, CQC. |
| 2, Q: What's your Payment method? |
| A: T/T 30% deposit, balance will be paid by T/T before delivery |
| B: 100% L/C before start production |
