Heavy Duty 10×4 Drive Diesel Road Wrecker Truck with 2 Seats
Price:
Factory price. Negotiable
MOQ:
1 unit
Delivery Time:
3months
Brand:
KaiFan
Product Description
Heavy Duty 10×4 Drive 12.8L EmissionDiesel Road Wrecker Truck with 2 seats 25% Max. Grade ability
1,Main Parameters
| Items | Value | |
| Lifting Structure | Rated Lifting weight | 15815 kg |
| Max. Lifting weight of original place | 35000 kg | |
| Max. Lifting weight of full extension boom | 12500 kg | |
| Rated towing weight | 54000 kg | |
| Max. Designed towing weight | 80000 kg | |
| Effective length of boom | 3670 m | |
| Extension traveling of boom | 1850 m | |
| Folding angle of boom | 90° | |
| Under lift Structure | Max. Rated hanging weight | 40000 kg |
| The height from hook to the ground | 13500mm | |
| Max. Extension traveling of lifting boom | 6000 mm | |
| Rotation angle | 360 ° | |
| Numbers of winch | 2 piece | |
| Rated pulling power of winch | 25000 kg | |
| Dia. Of steel cable | 26 mm | |
| Length of steel cable | 45 m | |
| Min. Speed of steel cable | 4 m/min | |
| Rotation angle | 65 ° | |
| Vehicle | External dimension | 11342×2500×3710mm |
| Parameters | Chassis model | FM440 104RB |
| Drive | 10×4 | |
| Axle base | 1995+2805+1400+1370 mm | |
| The whole weight of empty load | 38055 kg | |
| Load of front axle of empty load | 16885 kg | |
| Load of rear axle of empty load | 21170kg | |
| The whole weight of full load | 54000 kg | |
| Load of front axle of full load | 9000 kg | |
| Load of rear axle of full load | 10000/13000 kg | |
| Wheel base (front/rear axle) | 2029/1875 mm | |
| Front suspension | 1362 mm | |
| Rear suspension | 1750 mm | |
| Approach angle | 16.6 º | |
| Departure angle | 20 º | |
| Min. Turning diameter | 27.2 m | |
| Min. Ground clearance | 306 mm | |
| Max. Speed | 90km/h | |
| Max. Grade ability | 25% | |
| Gas consumption per one hundred miles(diesel oil) | 42.9L | |
| Engine model | D13 | |
| Engine emission | 12.8 L | |
| Rated power | 440/324/1400～1800 kw/r/min | |
| Torque | 2200/1050～1400 n·m/r/min | |
| Fuel type | Diesel | |
| Standard of emission | EN III | |
| Tire size | 315/80R22.5 | |
| Persons | 2 | |
2,Standard Equipments
- 1. VOLVO FM440 104RB
- 2. Main boom structure assembly
- 3. Vice boom assembly
- 4. Hanging hook assembly
- 5. Control structure assembly
- 6. Chain wheel and hanging assembly
- 7. Winch assembly (include winch clutch, impaction device)
- 8. Steel body assembly
- 9. Tool box assembly
- 10. Light stands assembly
- 11. Alarm device
- 12. Hydraulic system
- 13. Hydraulic system over voltage protection device
3,Working Condition
- 1,Altitude: 0-4500m
- 2,Temperature: -35℃--+45℃
- 3,Relative humidity: 80%
- 4,Wind force: ≤8degree
4,Working Range
KFM5540TQZ Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind
