540HP SINOTRUK HOWO T7H Heavy Duty Truck 8x4 8.5m Dump Truck 15.37 Ton
Price:
Factory price, negotiable
MOQ:
1 unit
Delivery Time:
90 days after sign contract
Brand:
Jindun
Product Description
SINOTRUK HOWO T7H heavy truck 540 horsepower 8X4 8.5m dump truck 15.37 ton rated load 11.665x 2.55x 3.635 size
Basic information
| Model | ZZ3317V466HE1 |
| Drive | 8X4 |
| Wheel base | 1950+4600+1400mm |
| Engine | Sinotruk MC13.54-50 |
| Gear box | Sinotruk HW25712XS |
| Rear axle ratio | 4.77 |
| Size (m) | 11.665x 2.55x 3.635 |
| Tread | Front track: 2041/2041mm; rear track: 1830/1830mm |
| Overall vehicle weight | 15.5 ton |
| Rated load | 15.37 ton |
| Total mass | 31 ton |
| Tonnage level | Heavy Truck |
| Approach angle | 16 |
| Departure angle | 22 |
Engine
| Model | Sinotruk MC13.54-50 |
| Number of cylinders | 6 |
| Fuel type | Diesel |
| Displacement | 12.419L |
| Emissions | Euro 5 |
| Maximum horsepower | 540hp |
| Maximum output power | 397kW |
| Torque | 2500N·m |
| Maximum torque speed | 1050-1350rpm |
| Rated speed | 1900rpm |
Container parameters
| Size (LWH) m | 8.5x2.35x1.5 |
| Container form | Back Dump |
Gear box
| Model | HW25712XS |
| Forward gear | 12 |
| Reverse gear | 2 |
| Tire specification | 12.00R20 18PR |
| Number of tires | 12 |
| Priming time | ≤80s |
| Fuel Tank capacity | 300L |
Chassis
| Front axle description | HF7 |
| Front axle allowable load | 6500/7000kg |
| Rear axle description | AC16 double rear axle |
| Rear axle allowable load | 17500 (two axis group) kg |
| Rear axle ratio | 4.77 |
| Number of springs | 11/11/12 |
