Full Load 54000KG Road Wrecker Truck 10×4 Drive Truck VOLVO FM440 104RB
Price:
USD
MOQ:
1
Delivery Time:
3months
Brand:
KaiFan
Product Description
The whole weight of full load 54000KG Road Wrecker Truck 90km/h 11342×2500×3710mm 10×4 Drive
1,Standard Equipments
1. VOLVO FM440 104RB
2. Main boom structure assembly
3. Vice boom assembly
4. Hanging hook assembly
5. Control structure assembly
6. Chain wheel and hanging assembly
7. Winch assembly (include winch clutch, impaction device)
8. Steel body assembly
9. Tool box assembly
10. Light stands assembly
11. Alarm device
12. Hydraulic system
13. Hydraulic system over voltage protection device
14. Electric system
15. PTO Warner
2,Working Condition
1,Altitude: 0-4500m
2,Temperature: -35℃--+45℃
3,Relative humidity: 80%
4,Wind force: ≤8degree
3,Main Parameters
| Items | Unit | Value | |
| Lifting Structure | Rated Lifting weight | kg | 15815 |
| Max. Lifting weight of original place | kg | 35000 | |
| Max. Lifting weight of full extension boom | kg | 12500 | |
| Rated towing weight | kg | 54000 | |
| Max. Designed towing weight | kg | 80000 | |
| Effective length of boom | m | 3670 | |
| Extension traveling of boom | m | 1850 | |
| Folding angle of boom | ° | 90 | |
| Under lift Structure | Max. Rated hanging weight | kg | 40000 |
| The height from hook to the ground | mm | 13500 | |
| Max. Extension traveling of lifting boom | mm | 6000 | |
| Rotation angle | ° | 360 | |
| Numbers of winch | piece | 2 | |
| Rated pulling power of winch | kg | 25000 | |
| Dia. Of steel cable | mm | 26 | |
| Length of steel cable | m | 45 | |
| Min. Speed of steel cable | m/min | 4 | |
| Rotation angle | ° | 65 | |
|
Vehicle Parameters |
External dimension | mm | 11342×2500×3710 |
| Chassis model | FM440 104RB | ||
| Drive | 10×4 | ||
| Axle base | mm | 1995+2805+1400+1370 | |
| The whole weight of empty load | kg | 38055 | |
| Load of front axle of empty load | kg | 16885 | |
| Load of rear axle of empty load | kg | 21170 | |
| The whole weight of full load | kg | 54000 | |
| Load of front axle of full load | kg | 9000 | |
| Load of rear axle of full load | kg | 10000/13000 | |
| Wheel base (front/rear axle) | mm | 2029/1875 | |
| Front suspension | mm | 1362 | |
| Rear suspension | mm | 1750 | |
| Approach angle | º | 16.6 | |
| Departure angle | º | 20 | |
| Min. Turning diameter | m | 27.2 | |
| Min. Ground clearance | mm | 306 | |
| Max. Speed | km/h | 90 | |
| Max. Grade ability | % | 25 | |
