Control Structure Big Truck Wrecker 0 - 4500m Altitude 45 Meters Length Steel Cable
Price:
USD
MOQ:
1
Delivery Time:
3months
Brand:
Young da
Product Description
Rated pulling power of winch 25000kg VOLVO Road Wrecker 45m Length of steel cable
one. Working Condition
1,Altitude: 0-4500m
2,Temperature: -35℃--+45℃
two. Main Parameters
| Items | Unit | Value | |
| Lifting Structure | Rated Lifting weight | kg | 15815 |
| Max. Lifting weight of original place | kg | 35000 | |
| Max. Lifting weight of full extension boom | kg | 12500 | |
| Rated towing weight | kg | 54000 | |
| Max. Designed towing weight | kg | 80000 | |
| Effective length of boom | m | 3670 | |
| Extension traveling of boom | m | 1850 | |
| Folding angle of boom | ° | 90 | |
| Under lift Structure | Max. Rated hanging weight | kg | 40000 |
| The height from hook to the ground | mm | 13500 | |
| Max. Extension traveling of lifting boom | mm | 6000 | |
| Rotation angle | ° | 360 | |
| Numbers of winch | piece | 2 | |
| Rated pulling power of winch | kg | 25000 | |
| Dia. Of steel cable | mm | 26 | |
| Length of steel cable | m | 45 | |
| Min. Speed of steel cable | m/min | 4 | |
| Rotation angle | ° | 65 | |
three. Standard Equipments
1. VOLVO FM440 104RB
2. Main boom structure assembly
3. Vice boom assembly
4. Hanging hook assembly
5. Control structure assembly
6. Chain wheel and hanging assembly
7. Winch assembly (include winch clutch, impaction device)
