Grade Ability 30% Recovery Wrecker Truck Heavy Wrecker Wrecker Truck Diesel Fuel
Grade Ability 30% Recovery Wrecker Truck Heavy Wrecker Wrecker Truck Diesel Fuel
Classisfication:
1.according to the wrecker operation ability
light type,medium type,heavy type and super duty type
2.according to the structural characteristics of operation device
supporting lifting separation type,supporting lifting combined body type,flat plate
one-pull-two,platform lifting type
3.according to the traction tonnage
1.5t, 3t, 5t, 8t, 10t, 15t, 25t, 30t, 50t, 60t, 80t, 100t.
4.best selling flat plate wrecker truck classification
plate floor type wrecker
straight plate type wrecker
super low slope type wrecker
flat plate with crane type wrecker
Chassis supply:
Dongfeng,Jac,Siontruck,Faw,Foton,Volvo,Nissan and others.
| Items | Unit | Value | |
| Lifting Structure | Rated Lifting weight | kg | 13765 |
| Max. Lifting weight of original place | kg | 18000 | |
| Max. Lifting weight of full extension boom | kg | 8000 | |
| Rated towing weight | kg | 44000 | |
| Max. Designed towing weight | kg | 60000 | |
| Effective length of boom | mm | 3350 | |
| Extension traveling of boom | mm | 1700 | |
| Folding angle of boom | ° | 90 | |
| Under lift Structure | Max. Rated hanging weight | kg | 25000 |
| The height from hook to the ground | mm | 13430 | |
| Max. Extension traveling of lifting boom | mm | 6000 | |
| Rotation angle | ° | 360 | |
| Numbers of winch | piece | 2 | |
| Rated pulling power of winch | kg | 2×15000 | |
| Dia. Of steel cable | mm | 22.4 | |
| Length of steel cable | m | 40 | |
| Min. Speed of steel cable | m/min | 4 | |
| Rotation angle | ° | 65 | |
|
Vehicle Parameters |
External dimension | mm | 10741×2500×3366 |
| Chassis model | FM400 84RB | ||
| Drive | 8×4 | ||
| Axle base | mm | 1995+4405+1370 | |
| The whole weight of empty load | kg | 30040 | |
| Load of front axle of empty load | kg | 14380 | |
| Load of rear axle of empty load | kg | 15660 | |
| The whole weight of full load | kg | 44000 | |
| Load of front axle of full load | kg | 9000/9000 | |
| Load of rear axle of full load | kg | 13000/13000 | |
| Wheel base (front/rear axle) | mm | 2019/1834 | |
| Front suspension | mm | 1362 | |
| Rear suspension | mm | 935 | |
| Approach angle | º | 16.6 | |
| Departure angle | º | 20 | |
