31000kg 360° Heavy Duty Road Wrecker Truck Max Speed 102km/H 338hp Horsepower

Truck name

HOWO wrecker

Overall dimension

11310*2500*3200mm

Total mass

31000kg

Curb weight

20770kg

Chassis model

ZZ1317N4667D1H

Max speed

102km/h

Front track

2022/2022,2041/2041

Rear track

1830/1830

Wheelbase

1800+4600+1350

Tyre size

315/80R22.5 16PR

Wheel load

6500/7000/17500

F/R hanging

1500/2060,1500/2180

Engine model

D10.34-40

Standard

Euro IV

Engine manufacture

HOWO

Horsepower

338hp

This truck can loading a 50tons car
And the crane have 2 12.5tons winch .
Configuration :Towing separate hanging tops can rotate 360 °,
three hexagonal boom, three corbel, the maximum towing mass 48 tons ,
maximum hoisting capacity 25 tons, fully extended horizontal state is the largest lifting 12.5 tons, the largest crane lifting 40 tons, Fully extended the maximum lifting capacity is 4.5Tons, the maximum lifting height of 12070mm, split compartment, bilateral linkage operation, open front legs, telescopic rear leg. Bilateral linkage operation device with the remote operation device (remote control) front bumper assembly weight, rear three working lights, two 150KN hydraulic winch (15 tons) ,40m rope, a wash tank, U-shaped holding tire. Forks 5 pairs, one pair of yoke bracket, chain hook 2, a long row of engineering lights (LED) ,1 set assist lamp . 1 set of auxiliary brake pipe assembly.
