Heavy Duty Remote Water Supply System Fire Truck Wireless Control Water Supply
Heavy Duty Remote Water Supply System Fire Truck Wireless Control Water Supply
System Configuration
1 Pumping Fire Truck+ 1 Hose Equipped fire truck+ 1 Equipment Fire Vehicle(Based on water supply distance determine the quantity of Hose Equipped fire truck. Based on water hose bridge and water supply equipment determine the quantity of Hose Equipment fire vehicle)
System Function
1)With fire fighting supply, fire control, flood drainage and rescue fuctions
2)The water intake pump could get water vertically from≥30m deep-water source with≥400L/S rated rate.
3)The system coudld deliver water ≥3000m with ≥400L/S rate during horizontal dual pumper operation,terminal water supply pressure≥0.2Mpa.
4)The system coudld deliver water ≥5000m with ≥200L/S rate during horizontal single pumper operation,terminal water supply pressure≥0.2Mpa.
| Pumping Fire Truck | |||||
| Description | |||||
| 1 | Chassis | Chassis Model | HOWO ZZ5357TXFV464ME1 | ||
| Drive Type | 6×4 | ||||
| Brake Type | ABS | ||||
| 2 | Transmission | Type | Manual 12(10 forward,2 reverse) | ||
| Model | HW19710 | ||||
| 3 | Key Data | Overall(L×W×H)(mm) | 11800×2500×3950 | ||
| Gross Weight(kg) | 33000 | ||||
| Wheelbase(mm) | 5800+1400 | ||||
| 4 | Tyre | Number | 10 | ||
| Size | 12.00R20 | ||||
| 5 | Engine | Model | MC11.40-50 | ||
| Power | 294kw | ||||
| RPM(r/min) | 1900 | ||||
| Emission Standard | Euro 4 | ||||
| Manufacturer | CNHTC | ||||
| Max Speed(km/h) | 90 | ||||
| Fuel Type | Diesel | ||||
| 6 | Axle | Number | 3 | ||
| Back Axle | 13t×2 | ||||
| Front Axle | 9t | ||||
| Rear Overhang(mm) | 3200 | ||||
| 7 | Cab | Seat | 2 | ||
| Drive Type | Left-hand drive | ||||
| Door | 2 | ||||
| Air-condition | Original | ||||
| Seat belt | Deluxe | ||||
| Interior | Deluxe | ||||
| CD Player | USB interfac audio Player | ||||
| 8 | Special function | PTO | Power take-off | ||
| 9 | Key technical Data | Water Carrier | Chassis | Type | Crawler-type |
| Speed(km/h) | 2.2～4.2 | ||||
| Climbing ability | 40% | ||||
| Engine | Brand | CUMMINS | |||
| Power | ≥650HP | ||||
| Floating Fire Pump(2) | Rate(L/S) | 200 | |||
| Pressure(MPa) | 0.4 | ||||
| Fork Arm | Max extent(m) | ≥4 | |||
| Max lifting weight(kg) | ≥400 | ||||
| Plus winch carring capacity(kg) | ≥800 | ||||
| Plus winch wirerope length(m) | ≥30 | ||||
| Hydraulic System | Hydraulic Pump(2) | Displacement:≥180mL/r,Oil pressure:≥35MPa | |||
| Hydraulic Motor(2) | Displacement:≥100mL/r,Oil pressure:≥35MPa | ||||
| Hydraulic Valve | Rate:≥300L/min,Oil pressure:≥35MPa | ||||
| Electrical Control System | Control type | Wireless Remote Control(Distance:≥100m)+Emergency hand control | |||
| LCD | Real-time display engine speed, system voltage, engine coolant temperature, oil pressure, working time, hydraulic oil temperature, etc. | ||||
| Pressurization system | Engine | Brand | CUMMINS | ||
| Power | ≥650HP | ||||
| Booster pump | Rate(L/S) | 400 | |||
| Pressure(MPa) | 0.8 | ||||
| Electrical Control System | LCD | Real-time display engine speed, system voltage, engine coolant temperature, oil pressure, working time, etc. | |||
| Central straight arm truck trane | Load Moment(t.m) | ≥18 | |||
| Maximum reach of crane(m) | ≥16 | ||||
| Lifting weight with maximum reach of crane(kg) | ≥400 | ||||
| Floating Fire Pump Winch carring capacity(kg) | ≥800 | ||||
| Floating Fire Pump Winch wirerope length(m) | ≥50 | ||||
| Water Hose Winch carring capacity(kg) | ≥4000 | ||||
| Water Hose Winch wirerope length(m) | ≥20 | ||||
