Long Distance Water Supply Big Fire Trucks , Fire Service Truck 400HP Power
Long Distance Water Supply Big Fire Trucks , Fire Service Truck 400HP Power
1, Chassis
| Chassis model | SINOTRUK HOWO ZZ5357TXFV464ME1 |
| Discharge | CHINA V |
| Drive | 6×4 |
| Engine model | MC11.40-50 |
| Engine power | 400HP |
| Gross weight | 35t(front axle 9t,rear axle 26t) |
| Max. speed | ≥90Km/h |
| Cab | single row with sleeping berth |
2. Transport platform and water intake module
Transport platform using high strength steel welding materials, equipment box using LF2 antirust aluminum flat mask.
The hydraulic support legs are arranged on the rear of the vehicle to ensure the safe and reliable upper and lower carrying platform of the water intake module. The water intake module is hydraulic turning type. The rear part of the vehicle is provided with a hydraulic supporting leg, which ensures the safe and reliable upper and lower carrying platform of the water intake module.
3,Crawler tracking water intaking truck
Crawler tracking water intaking truck is composed of a power system, crawler system, floating boat pump, crane system, hydraulic system, electric control system, frame, etc. Can remote control the water module vehicles running to the water source for water operations.
1) power system
Engine:Commins
Power: 750HP
2) crawler tracking system
Traveling speed: 2.2～4.2km/h
Gradeability: 40%
Illuminating system: equipped with searchlight, be provided with night water intaking lighting function.
pumping truck onboard equipment
|
|
Name |
Specification |
No. |
Notes |
|---|---|---|---|---|
| 1 | Liner hose assembly | 10-250-20 | 2 | |
| 2 | Liner hose assembly | 10-250-10 | 2 | |
| 3 | Liner hose assembly | 10-250-5 | 2 | |
| 4 | Hose connection wrench | General type | 4 | |
| 5 | Vertical water supply bend | DN250 | 2 | |
| 6 | Hydraulic rubber tube protector | General type | 1 | |
| 7 | Highlight flashlight | 2 | ||
| 8 |
Handheld anti-explosion interphone |
1 | ||
| 9 | Chassis onboard tools | Standard |
