SS304 7 Ton Foam and Water Combined Tanker Fire Truck with Foam Proportioner
SS304 7 Ton Foam and Water Combined Tanker Fire Truck with Foam Proportioner
Vehicle
| Model | JDX5180GXFPM70 | |
| Chassis | Brand | MAN (MADE IN GERMANY) |
| Chassis Model | TGM18.290 4X2 BB | |
| Power | 213KW | |
| Steering wheel | right hand drive | |
| Chassis weight | 5645Kg | |
| Full total mass | 17600Kg | |
| Drive Type | 4 × 2 | |
| Wheelbase | 4425 mm | |
| Engine Model | MAN D0836LFL30 | |
| Number of cylinders | 6 | |
| Type | 4-stroke, water-cooled, four-valve, diesel, turbocharged, intercooled, electronically controlled | |
| Engine power | 213/2300 kw/rpm | |
| Displacement | 6871mm | |
| Emission standard | Euro 4 standard | |
| Torque | 1150/1200 ~ 1750 Nm/Rpm | |
| Transmission type | ZF 9S-1310 OD manual transmission | |
| Number of gears | 9 + 1 | |
| Clutch | Monolithic, dry type, with buffer springs, hydraulicPressure booster | |
| PTO type | ZF N109 / 10b | |
| Dimensions | ≤8500X2500X3500mm | |
| Fire-extinguishing Agents | Foam(kg) | 1500 |
| Water(kg) | 5500 | |
Equipment layout principles
- According to combat programming and combat development design equipment integration.
- According to human body engineering principle design all kinds of equipment frames.
- According to using logic and frequency of use place equipment.
- 1-2 action can take any equipment standing on the ground or pedal.
- Fixed all equipment with rust-proof, vibration-proof, anti-drop, scratch-proof special clamp.
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
6. Q: What's your main product?
A: Our main product include : water & foam tank trucks, CAFS fire trucks, chemical fire trucks, emergency rescue vehicles, lighting trucks, aerial ladder and platform trucks, airport fire trucks, water tower fire trucks and other general fire trucks. The products have been sold to more than 20 countries.
Any other questions, please do not hesitate to contact with us.
