Pick Up 300L 4 Cylinders 3600rmp 161HP SUV Fire Truck
Water Mist 300L Water Tank Pick-Up Fire Truck 57 Fuel Tank 161 Max House Power
Main feature:
Ø Excellent performance of chassis:strong dynamics, good throughput capacity, reliable and durable.
Ø The vehicle is smart, graceful lines, compact structure, short body, small turning radius, flexibly running in urban and rural. It’s suitable for all kinds of small fire, forest fire and fire inspection. This device can be equipped with all the professional rescue teams or disasters rescue team..
Ø The vehicle is equipped with a 300L fix water tank. The water mist system set on the carriage in the equipment room with compact structure. The water mist system equipped with at least 30m hose reel. Moreover, there is a shelf in the equipment room to store common equipments, dramatically shorten the prepare time to fire fighting.
Key component structure and technical performance parameter
| ⑴ Vehicle | |
| 1. Overall (mm): | 5310×1880×2300 |
| 2. Gross weight G.V.W (kg): | 2950 |
| 3. Seat (inc. driver): | 2+3 |
| 5. Max. power (kw): | 120 |
| 6. Max. torque (N.m/rpm): | 360 |
| 7. Fuel tank (L): | 57 |
| ⑵ Engine | |
| Engine model: | Commins ISF2.8s4161P |
| Engine type: | 4 cylinders, pressuring air intercool, EGR+DOC |
| Max. power rotate speed (rpm): | 3600 |
| Max. torque rotate speed (rpm): | 1800-3000 |
| Max. HP: | 161 |
| Displacement mL: | 2780 |
| Cylinders: | 4 |
| Gears: | 5 |
| Fuel type: | Diesel |
| Emission standard: | China 4 |
| Tyre type: | 245/70R16 |
Additional documents
1. The chassis operation manual
2. The chassis quality assurance manual
3. The chassis quality certificate
4. The chassis VIN number copy.
5. Engine number copy
6. The accessory tools list of the chassis
7. The fire fighting truck quality certificate
8. The fire fighting truck specification
9. The accessory equipment list of the fire fighting truck
10. The fire fighting truck hand-over list
