177KW 4x2 Drive 95Km/H 98 pcs Fire Equipment Emergency Rescue Vehicle
177KW 4x2 Drive 95Km/H 98 pcs Fire Equipment Emergency Rescue Vehicle
JDX5130TXFJY98 rescue fire truck adopts ISUZU QL1160AMFRY chassis, equipped with a 4X1000W lighting system, Honda ET12000 generator, Finland HIAB 111 B-2CLX cranes and emergency lighting equipment, vehicle structure and reasonable layout, convenient operation and maintenance, applicable to large and medium city public security fire brigade, petrochemical enterprises and airport fire brigade for emergency vehicle. Its shape, structure , the performance of the maintenance system to achieve the level of similar imported vehicles and life expectancy.
Overall size
| Dimensions: length x width x height | 8340×2460×3380 mm |
| The full authorized total mass | 13000kg |
| Vehicle kerb mass | 12550kg |
| The number of rescue equipment(pieces) | 98 |
| Crew number(including driver) | 6 |
| Maximum power | 177/240 kw/hp |
Lift lighting system:
Lift lighting electrical system by 13KW Honda generator, 4.0kW main lighting, 2X0.5KW mobile lighting lamps, raised about 8m (off) the pneumatic lift system, electrical control cabinet and other components.
Generator:
| Model | Gasoline generator ET12000 (Honda power) |
| Rated output power | 10 KVA(Three-phase),2.7kVA×3(Single-phase) |
| Maximum output power | 11 KVA(Three-phase),3.0kVA×3(Single-phase) |
| Power factor | 0.8 |
| Voltage | 380/220 V |
| Electric current | 1.6A×3(Single-phase),14.4A |
| Frequency | 50HZ |
| Fuel | Gasoline |
| Continuous working time | 6.5 hours |
Lifting lighting system:
| Manufacturer | Zhejiang SENKEN |
| Model | SG 65-41000G |
| Lifting height | 6.5M |
| AGL | ≥7.6m |
| Control system voltage | DC24V |
| Lamp voltage | 220V |
| Lamp power | 4 × 1000W |
| Lamps horizontal rotation angle | 380 ° |
| Lamps vertical rotation angle | 330 ° |
| Lamp luminous flux | 220000lm |
