Carbon Steel 7600L Water 400L Foam Fire Truck 1.0Mpa
High Balance Precision Transmission Shaft Water And Foam Fire Trucks 20490Kg Max Load
Liquid tank
| Capacity | Water: 7600kg |
| Material | Qualitative carbon steel |
| Structure | Total side girder |
| Device |
1 ingate 1 overflow device 1 liquid level sensor 1 DN40 drain outlet with valve 4 DN80 filling pipe end Conform to rule GA39.4-92 |
Side girder
Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.
Equipment tank
| Material | Q235A high quality steel combine with porous steel |
| Structure | Split type welding structure |
| Internal structure | the inner frame for the introduction of aluminum lap technology, can maximize space utilization and variability within the equipment, users can request allocation of various sliding bracket, carriage, rotating frame, and high strength plastic storage box and so on, the structure from the space utilization, aesthetic appearance, ease of handling equipment have reached the international advanced level. |
Pedal plate
Location: At the bottom of roller shutter door.
Material: Steel frame covered by aluminum alloy checkered plate
Structure: adopt the gas springs plus shutter fasten, safe and
Reliable, each petal plate bearing ≥150Kg
Dash board and on-board equipment
Cab PTO gear switch
Pump room
| Function switch | lighting, water outlet, water injection, liquid outlet, monitor shot |
| Dash board | Pressure gauge, Water gauge, vacuum gauge, content gauge, tachometer |
Electrical system
The main lights in the cab at the top of the long row of lights, configure the 100W alarm control system; a strobe lights installed on both sides and the middle of each compartment (two red and blue)
