30% Maximum Climbing Ability Rescue Fire Fighting Vehicle 100km/H Maximum Speed

JY98/H5 rescue fire truck is a fire truck that modified with SINOTRUK HOWO chassis. It has many functions such as demolition, traction, lifting, lighting, etc. It can deal with accidents like traffic accidents and natural disasters.

Model: SG65-41000G (Interstellar)

Lifting Height: 6.45m

Terrain clearance: ≥7.5m

Control system operating voltage: DC24V

Lamp operating voltage: 220V

Lamp power: 1000W

Horizontal rotation angle of the lamp: 　 360°

Vertical rotation angle of the lamp: 　　　360°

Electric winch

Model N12000XF(US Champion)

Voltage 24V

Winch rope length 38m

Maximum tension of winch 5t

Traction speed 3.57m/min

Deflection angle 10°

Model: SQ5ZK2(XCMG)

Maximum lifting mass: 5000kg

Maximum lifting moment: 10.5T.m

Swing moment: 1.2T.m

Maximum working range: 8m

Rotary range: 370°

System rated pressure: 30MPa
