Seat Type Electric Reach Truck Forklift , Narrow Aisle Reach Truck 6.2m Lifting Height
Price:
Negotiable
MOQ:
1 set
Delivery Time:
25 - 30 days
Brand:
REACH
Product Description
Electric reach truck 2ton 6.2m explosion proof forklift with explosion-proof sealed battery
Quick Details:
Rated load: 2000kg
Drive type: Electric
Operation type: Seated
Max. lifting height: 6200mm
Free lift: 2100mm
Reach distance: 600mm
Travel speed, laden/unladen: 8/8.3km/h
Max. gradeability, laden/unladen: 10/12%
Battery: 48V510AH
Advantages:
CQDEx AC type Electric forklift approved with Explosion-proof mark: Exsd II BT4, explosion-proof equipment for Category 2G, Offer high safety functions according to international standards.
Explosion-proof instrument with traveling switch and light direction switch.
Tool box and file folder.
Explosion type charger.
Forks with brass.
Legs with brass.
Chassis with brass.
| SPECIFICATIONS | ||
| Model | CQD20Ex | |
| Power | electric | |
| Operation type | seated | |
| Capacity/rated load | kg | 2000 |
| Lift height | mm | 6200 |
| Load center distance | mm | 500 |
| Load distance, centre of drive axle to fork | mm | 380 |
| Wheelbase | mm | 1466 |
| Axle loading, unladen front/rear | kg | 2550/1470 |
| Axle loading, fork advanced, laden front/rear | kg | 1003/5017 |
| Axle loading, fork retracted, laden front/rear | kg | 2394/3626 |
| Tyres type | polyurethane | |
| Drive wheel | mm | 406*152 |
| Fork wheel | mm | 406*152 |
| Tread, front | mm | ~ |
| Tread, rear | mm | 1180 |
| Tilt of mast/fork carriage forward/backward | Grad | 2,2(mast) |
| Height, mast lowered | mm | 2740 |
| Free lift | mm | 2100 |
| Height, mast extended | mm | 7000 |
| Height of overhead guard(cabin) | mm | 2200 |
| Seat height/stand height | mm | 1068 |
| Height of crura | mm | 270 |
| Overall length | mm | 2440 |
| Length to face of forks | mm | 1950 |
| Overall width | mm | 1378 |
| Fork dimensions | mm | 50/130/1070 |
| Fork carriage width | mm | 928 |
| Distance between fork-arms | mm | 680 |
| Distance between support arms/loading surfaces | mm | 900 |
| Reach distance | mm | 600 |
| Ground clearance, laden, below mast | mm | 90 |
| Ground clearance, centre of wheelbase | mm | 80 |
| Aisle width for pallets 1000*1200 crossways | mm | 2880 |
| Aisle width for pallets 800*1200 lengthways | mm | 2930 |
| Turning radius | mm | 1820 |
| Travel speed, laden/unladen | km/h | 8/8.3 |
| Lift speed, laden/unladen | mm/s | 190/200 |
| Lowering speed, laden/unladen | mm/s | 500/400 |
| Reaching speed, laden/unladen | mm/s | 100/100 |
| Max. gradeability, laden/unladen | % | 10/12 |
| Acceleration time, laden/unladen | s | 4.8/4.3 |
| Service brake | hydraulic | |
| Battery | V/Ah | 48/510 |
| Type of drive control | AC | |
| Sound level at the driver's ear acc. to DIN 12053 | dB(A) | 70 |
| Service weight | kg | 4020 |
