Rechargeable 1.2 V 40mah Nimh Button Cell 40H Solder Pins For Solar Lights
40H 1.2 Volt NiMH Button Cell Batteries 40mah 40H Button Cell Rechargeable Batteries for Solar lights
NiMH 40H 1.2V 43mAh Rechargeable Button Cell + Solder Pins
Ni-mh 1.2v 40mah 40H nimh button cell for Gamepad · 40mAh 1.2V Ni-Mh Button Cell Battery 30H Rechargeable nimh coin cell
1.2v 4.8V 40mah 80mah 160mah 20H B20H 30H 40H B40H 80H B80H 280H nimh button cell nimh rechargeable battery pack
NI-MH button cell:
Model: 20H,30H,40H,80H,110H,160H,250H,330H etc
Battery pack: 1.2V,2.4V,3.6V,4.8V,6V,7.2V,8.4V,9V,12V etc
40H1.2V Ni-MH BUTTON CELL
| Part number | 40H |
| Voltage | 1.2V |
| Capacity | 40mah |
|
Recommended Trickle Charge Current |
0.4~1.2mA |
|
Nominal Charge Current |
4mA |
|
Normal Charging Time |
14~16h |
|
Nominal Discharge Current |
8mA |
| Weight | 1.8g |
| Cycle Life | ≥500 |
| Discharge cut-off voltage | 1.0 v |
RATINGS
-
Nominal voltage : 1.2V
-
Nominal capacity : 40mAh/0.2CmA
-
Typical weight : 1.8g
-
Standard charge : 4mA×14hours
-
Rapid charge : 8mA×6.5hours
Trickle current : 0.4mA
Discharge cut-off voltage: 1.0V
Temperature range for operation (Humidity: Max.85%)
Standard charge 0~+35℃
Rapid charge 0~+35℃
Trickle charge 0~+35℃
Discharge 0~+35℃
Temperature range for storage (Humidity: Max.85%)
Within 1 years 0~+25℃
Within 6 months -20~+35℃
Within a month -20~+45℃
Within a week -20~+55℃
40H rechargeable battery NI-Mh 40mah battery
Coin cell NIMH battery 1.2v rechargeable button cell:
| Cell model | Voltage(V) | Capacity(mah) | Diameter(mm) | Height(mm) | Charge current(mA) | Discharge current(mA) | Weight(g) | Temperature(°C) |
| 20H | 1.2 | 20 | 11.7±0.1 | 3.2±0.2 | 2 | 4 | 1.5 | 0~45 |
| 40H | 1.2 | 40 | 11.7±0.1 | 5.2±0.2 | 4 | 8 | 1.8 | 0~45 |
| 60H | 1.2 | 60 | 15.3±0.1 | 6.1±0.2 | 6 | 12 | 2 | 0~45 |
| 80H | 1.2 | 80 | 15.3±0.1 | 6.1±0.2 | 8 | 16 | 3.5 | 0~45 |
| 110H | 1.2 | 110 | 15.3±0.1 | 7.7±0.2 | 10 | 20 | 4.5 | 0~45 |
| 160H | 1.2 | 150 | 24.5*14±0.1 | 5.2±0.2 | 15 | 30 | 6 | 0~45 |
| 250H | 1.2 | 250 | 25±0.1 | 6.3±0.2 | 25 | 50 | 10 | 0~45 |
| 330H | 1.2 | 330 | 25±0.1 | 8.4±0.2 | 30 | 60 | 12.5 | 0~45 |
