FEP Release Film / Transparent / High Thermal Conductivity Fep Film
FEP Shrink Tubing / FEP Coiled Tube / Pipe / PASS 97-99% UV Light
Brief Introduction
FEP film is a transparent,thermoplastic film that can be heat sealed,thermoformed,vaccum formed,heat bonded,welded,metalized,laminated combined with dozens of other materials,and can be used as an excellent hot-melt adhesive.
This wide variety of fabrication possibilities combines with the following important properties to offer a unique balance of capabilities not available in any other plastic film.
Techyours® FEP Films Feature
*Most chemically inert of all plastics
*Withstands both high and low temperature extremes
*Outstanding weather resistance
*Excellent optical characteristics
*Superior electrical properties
*Free of plasticizers or additives
*Excellent processibility with conventional thermoplastic methods
Specification of FEP Film (can be customized)
| Item | Thickness(mm) | Thickness Tolerance |
Width(mm) | Item | Thickness(mm) | Thickness Tolerance |
Width(mm) |
| High-density | 0.015 | 0~+0.01 | 10-120 | Common | 0.03 | 0~+10% | 30-1500 |
| 0.02 | 0.05 | ||||||
| 0.03 | 0.08 | ||||||
| 0.04 | 0.10 | ||||||
| 0.05 | 0.15 | ||||||
| 0.07 | 0.20 | ||||||
| 0.08 | 0.25 | ||||||
| 0.90 | 0.30 | ||||||
| 0.10 | 0.40 | ||||||
| 0.15 | 0.50 |
Main Properties of FEP Film
Characteristics:
| Density | Melting Point | Volume resistivity | Tensile Strength(23℃) | Elongation at break(23℃) |
| 2.15g/cc | 270℃ | 1015Ω·m | ≥19MPa | 250%-330% |
Standard Size:
| Thickness | Width | Length | Remark |
| 25μm | 1200mm | 100~200m/Roll | Customed Size is ok,also can surface treated. |
| 50μm | 1200mm | 100~200m/Roll | |
| 75μm | 1200mm | 100~200m/Roll | |
| 100μm | 1200mm |
100~200m/Roll |
