Sinotruk HOWO 6X4 Sprinkler Tank Truck

Price Negotiable
Price: Negotiable
MOQ: 1
Delivery Time: 30days
Brand: sinotruk
Product Description
Hot Sale Sinotruk HOWO 6X4 320-450HP 20m3 Water Bowser Tanker Sprinkler Tank Truck
Products Description
Details Images

A Water Tank Truck is a specialized vehicle designed for transporting and distributing water. It is commonly used for

purposes such as irrigation, firefighting, road spraying, and providing potable water in emergency situations. The key

feature of a Water Tank Truck is its large-capacity water tank, which can be customized to carry varying volumes of

water, ranging from several thousand to tens of thousands of liters.

Typically consisting of a chassis, power system, water tank, and associated piping, the Water Tank Truck is built to

withstand the weight of a full tank and operate effectively across diverse road and terrain conditions. Powered by a

diesel engine, the vehicle provides sufficient horsepower to drive both itself and its water pumping systems.

The design of the water tank ensures secure transport and storage of water, utilizing high-strength materials to prevent

leaks and contamination. Equipped with specialized pumps and piping systems, Water Tank Trucks facilitate the efficient

distribution of water, either through spray systems or direct loading via hoses, to targeted locations.

In emergency scenarios, Water Tank Trucks play a critical role in swiftly delivering essential water supplies to disaster

areas or other locations in need. They also contribute to urban maintenance and cleanliness by regularly spraying water

to control dust and maintain environmental hygiene on roads.

In summary, a Water Tank Truck is a versatile specialized vehicle that serves vital roles across various contexts, ensuring

efficient utilization and distribution of water resources.

Dimension(Lx W xH)(unloaded)
9895×2496×2958
Tanker volume(m³)

20m3

Tank body(thickness):5mm,material:carbon steel;
sprinkling equipment both in front and in rear; special anti-corrosion treatment
Approaching angle/Departure angle(°)
13.5/11.5
Overhang(front/rear) (mm)
1500/2445
Wheel base (mm)
4600+1350
Max speed(km/h)
75
Curb weight(kg)
12400
Rated Loading Weight(kg)
12450
Engine
(Steyr technology, made in China)
Model
WD615.47,water-cooled,four strokes,6 cylinders in line with water cooling,directly injection
Fuel type
Diesel
Horse Power, max(kw/rpm)
400HP
Emission
EURO 2
Fuel tanker capacity
300
Transmission
Model
HW19710, 10 forward, 2 reverse
Brake system
Service brake
Dual circuit compressed air brake
Parking brake
spring energy, compressed air operating on rear wheels
Steering system
Model
ZF8118
Front axle
HF7 , Steering with double T-cross section beam
Rear axle
HW12
Color
White,Red,Yellow. According to the customer
Tyre
1100R20
Electrical system
Battery
2X12V/165Ah
Alternator
28V-1500kw
Starter
7.5Kw/24V
Cab
HOWO 76 cab,
