Rescue Fire Truck 4x2 251hp - 350hp SINOTRUK HOWO Fire Fighter Truck 6m3 Water Tank
Rescue Fire Truck 4x2 251 - 350hp SINOTRUK HOWO 6m3 fire fighting truck water tank with foam tank
Quick Details of Rescue Fire Truck
| Drive Wheel: | 4x2 | Type: | Tanker | Transmission Type: | Manual |
| Condition: | New | Horsepower: | 251 - 350hp | Tank Capacity: | 3001 - 5000L |
| Emission Standard: | Euro 3 | Fuel Type: | Diesel | Max. Work Height: | 60m |
| Size: | 8570X2500x3570 | Place of Origin: | China (Mainland) | Brand Name: | SHMC |
| Model Number: | SHMC5256 | Logo Printing: | Available | Color: | Optional |
General Information
| Place of Origin: | CHINA CNHTC |
| Brand Name: | SINOTRUK HOWO |
| Model Number: | SHMC5256 |
| Certification: | ISO,CCC |
Product Commercial Item
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | Nude |
| Delivery Time: | Within 20-30 days after the receipt of the deposit |
| Payment Terms: | LC/TT etc |
| Supply Ability: | 100 units per week |
Description:
1.Sino Heavy Machinery Co,Ltd is the authorized company of SINOTRUK(CNHTC), and mainly deal with heavy duty trucks /all spare parts and service We supply HOWO, STEYR, STEYR KING, GOLDEN PRINCE, HOHAN series 4X2, 6X4, and 8X4 dump trucks, tractor trucks, cargo trucks, garbage trucks, oil tank trucks, water tank trucks, log trailers tractors, terminal tractors, etc. Our products arrange from 190 horse power to 410 horse power, and loading capacity cover from 5 tons to 50 tons.
2.Specification
| SPECIFICATIONS FOR FIRE TRUCK | |||
| Name | Fire-extinguisher water tanker | ||
| Model | KWZ5190GXFPM80H | ||
| Chassis Type | ZZ1167M4617C | ||
| Driving Type | 4x2 | ||
| Wheel Base (Mm) | 4600 | ||
| Seating capacity | 6 | ||
| ENGINE | |||
| Type | WD615.92C | ||
| Power(KW) | 198 | ||
| Torsion | 1190N·m(1200-1500r/min) | ||
| DIMENSION PARAMETER | |||
| Dimension (Mm)L×W×H | 8570×2500×3570 | ||
| Overhang(Mm) | Front | 1500mm | |
| Rear | 2310mm | ||
| Approach Angle/Departure Angle | 16°/13° | ||
| min ground clearance | 260mm | ||
| FUNCTION PARAMETER | |||
| Turning Diameter | 17m | ||
| Maximum Speed(Km/H) | ≤ 90km/h | ||
| LOAD CAPACITY | |||
| Maximum Authorized Total Mass | 10950kg | ||
| Water | 8000kg | ||
| FIRE-FIGHTING EQUIPMENT | |||
| Fire Pump | flow | 60or30L/S | |
| pressure | 1.0or2.0Mpa | ||
| Primer Pump | depth | ≥ 7m | |
| time | ≤ 50s | ||
| Fire Monitor | location | truck roof in central | |
| flow(l/s) | 50 | ||
| pressure(mpa) | ≤1.0 | ||
| flow | 50L/S | ||
| range(m) | ≥70 | ||
| rotation angle | ≥360 | ||
| angle of altitude | ≥+80° | ||
| angle of depression | ≤-15° | ||
