All Terrain QY35K5 Truck Mounted Crane Fuel Type 14.3m Lifting Height
14.3m Lifting Height All Terrain type Truck Crane QY35K5
Specification
| Classificatory | Item | Unit | Parameter | |||
|
Main performance |
Max. total rated lifting capacity | t | 160 | |||
| Min. rated working radius | m | 3 | ||||
| Turning radius at turntable tail | mm | 4850 | ||||
| Max. load moment | Base boom | kN.m | 5282 | |||
| Fully extended boom | kN.m | 2140 | ||||
| Outrigger span | Longitudinal | m | 9.625 | |||
| Lateral | m | 8.7(6.5) | ||||
| Lifting height | Base boom | m | 14.3 | |||
| Fully extended boom | m | 56.3 | ||||
| Fully extended boom + Jib | m | 79 | ||||
| Boom length | Base boom | m | 13.6 | |||
| Fully extended boom | m | 60 | ||||
| Fully extended boom + Jib | m | 80 | ||||
| Jib offset | ° | 0,15,30 | ||||
|
Working speed |
Boom elevating time | Boom raising | s | 90 | ||
| Boom telescoping time | Boom full extension | s | 600 | |||
| Boom full retraction | s | 600 | ||||
| Max. swing speed | r/min | 2 | ||||
| Hoist speed (single rope at 4th layer) | Main winch | No load | m/min | 120 | ||
| Aux. winch | No load | m/min | 110 | |||
| Crane exterior noise | db(A) | ≤118 | ||||
| At seated position | db(A) | ≤90 | ||||
Quick detail:
Condition: Brand New Fuel Type:Diesel
Place of Origin:Shandong, China (Mainland)
Description:
We are specialized in heavy field for almost one decade, we have great experiences no matter in service and spare parts supply. So we are the credible partner for you.
Advantages
Wide cab
Five-segment U section boom
Single cylinder luffing and double-winch
Manual mechanical control
Spacious and luxury streamline cab
U boom system
Constantly optimize the boom section, completely releasing the carrying capacity of the plates, which makes the lifting more reliable and safer.
Compact boom head
Extend the jib length, which can extend the working radius to the most.
Hydraulic pipeline
The pipeline adopts high-precision cold drawing steel pipe, matching with the cutting ferrule, which is good looking and easy to maintain.
Operating cab
It has large space and wide views. The control levers and instrument buttons are at hand.
Torque limiter
The colorful LCD display of the torque limiter can shows all the important operating information.
Engine
Reasonable matching, energy efficiency and environmental protection, and strong power meet the economical running of the required power.
Tag: motocrane/automobile crane/crane truck/crane car/truck crane Autohoist
