6x4 20000L Sinotruk Howo Tanker Truck 371hp LHD Driving
Price:
USD 40000-50000/Unit
MOQ:
1 Unit
Delivery Time:
30 Working Days
Brand:
howo
Product Description
Sinotruk Howo 371hp 6x4 20000L Fuel Tanker Truck
|
Product Name
|
SINOTRUK HOWO 6X4 Fuel Tanker Truck
|
|
Chassis Model
|
ZZ1267N4641W
|
|
Driving Type
|
LHD (RHD is optional)
|
|
Cabin
|
HW76 cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn,air conditioner , with transverse stabilizer, with 4-point support fully floating suspension + shock absorber.
|
|
Engine
|
Make: SINOTRUK
Diesel 4-stroke direct injection diesel engine Engine model: WD615.69, Euro 2, 336 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L |
|
Transmission
|
HW19710, 10F & 2R, with PTO
Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2) |
|
Steering
|
ZF power steering, model ZF8118, hydraulic steering with power assistance
|
|
Front Axle
|
HF9,1x9000 KGS
Steering with a doubleT-cross section beam
|
|
Rear Axle
|
HC16, 2x16000 KGS
Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles.
Ratio:5.73
|
|
Propeller Shaft
|
Double universal joint propeller shaft with gear-shaped coupling flange
|
|
Chassis
|
Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members
Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer |
|
Brake
|
Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake |
|
Electrics
|
Operating voltage: 24 V, negative grounded
Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
|
Tyres
|
295/80R22.5, tubeless tyres with one spare tyre
|
|
Fuel Tank
|
300L
|
|
Mixer Body
|
Tank Body: 20 Cubic Meters
Compartments:2 With refueling machine |
|
Overall Dimension
|
9000*2550*3360 mm
|
