H12V190ZLD jinan diesel engine and engine parts chidong CO1200/20
6000 Series (1350~2000Kw) Diesel Generator
· Price: - /
· Place of Origin:Shandong China (Mainland)
· Speed:1000~1500
· Port:QINGDAO
· Rated Current:10824
· Related Website;www.jichaigreenpower.com
Item specifics
Place of Origin: Shandong China (Mainland)
Speed: 1000~1500
Port: QINGDAO
Rated Current: 10824
Frequency: 50
Model Number: 6000 Diesel Generating Set
Rated Voltage: 400/230
Output Type: AC Three Phase
Payment Terms: L/C,T/T
Brand Name: Ji Chai
Diesel Generator: Diesel Generator
Rated Power: 1350~2000KW
Supply Ability: 400 Set/Sets per Month
Specifications
6000 Series (1350~2000Kw) Diesel Generator
1. Newly-designed by adopting modern technology from AVL of Austria
6000 Series (1350~2000Kw) Diesel Generator
Description of 6000 Diesel Generating Set:
1. Newly-designed by adopting modern technology from AVL of Austria
2. Power: 1350~2000 KW
3. Rated voltage: 400/230 V
4. No-load voltage regulation: 95~105% of rated voltage
5. Different kind of generators is available to meet customers specific requirements
Applications:
With the powerful 6000-diesel engine, this genset is widely used in power plants.
Specification of 6000 Diesel Generating Set:
| Set model |
Diesel engine model |
Generator model | Rated power(KW) | Rated voltage (V) |
Rated frequency (HZ) | Overall dimensions L*B*H (mm) |
Net weight (Kg) |
| 1350GF | H12V190ZL | DIGI1308/4 | 1350 | 400/230 | 50 | 7880×2869×3175 | 19100 |
| 1350GF-K | H12V190ZLD | 1FC6566-4TA42 | 1350 | 400/230 | 50 | 5930×2180×2421 | 17000 |
| 1350GFZ | H12V190PZLD | 1FC6566-4TA42 | 1350 | 400/230 | 50 | 7880×2869×3175 | 19500 |
| 1500GF | H12V190ZL | 1FC6566-4TA42 | 1500 | 400/230 | 50 | 7880×2869×3175 | 19500 |
| 1500GF-K | H12V190ZL | HCI734H2 | 1500 | 400/230 | 50 | 5930×2180×2421 | 17000 |
| 1500GFZ | H12V190ZLD | 1FC6566-4TA42-Z | 1500 | 400/230 | 50 | 7880×2869×3175 | 19500 |
| 2000GF | H16V190ZLD | 1FC5636-4BA42 | 2000 | 400/230 | 50 | 9060×2869×3175 | 24000 |
| 2000GF-K | H16V190ZLD | 1FC5636-4BA42 | 2000 | 400/230 | 50 | 7150×2180×2421 | 21000 |
| 2000GFZ | H16V190ZLD | 1FC5636-4BA42 | 2000 | 400/230 | 50 | 9060×2869×3175 | 24000 |
Main Electrical Performance Data:
| Voltage | Frequency | ||||||
| Steady-state adjusting rate | Transient-state adjusting rate | Stable time | Fluctuation rate | Steady-state adjusting rate | Transient-state adjusting rate | Stable time | Fluctuation rate |
| ±2.5% | 15%~+20% | 1.5S | 0.5% | 5% | ±10% | 7S | 0.5% |
| Voltage regulation range: no-load voltage regulation: 95~105% of rated voltage |
Control Panel
The control panel of the diesel generating set is mainly used to control the power transmission of generator sets, providing protections for lack-voltage, over-current, automatic speed regulation and reverse power. Meanwhile, it also can monitor such parameters as revs, water temperature, oil temperature, oil pressure and exhaust temperature, with a sound-light alarming output system.
