Security & Protection Other Security & Protection Products

Unicomp Clothes / Garments Food And Beverage X Ray Inspection Systems 40-120kV

Price Negotiable
Price: USD
MOQ: 1
Delivery Time: 1-3 months
Brand: Unicomp
Product Description

Unicomp clothes garments X-ray Inspection Systems in Food Processing Plants detecting foreign matter



Unicomp Efficient X-ray inspection systems are available for systematic detection and elimination of foreign material. They help food makers safeguard consumer health, mitigate the risk for extensive recall campaigns, and make sure that the reputation of their brands and compliance with applicable regulations remain intact.



X-ray inspection systems are used wherever defects need to be detected by non-destructive means. The spectrum of use is broad and includes a wide range of different sectors and inspection tasks, from testing of materials for cracks and air inclusions to foreign matter inclusions and shape deviations. In the electronics industry, too, the increased use of miniature housings and the trend toward moving components inside the electronic assembly require high quality inspection that catches hidden defects cost-effectively and with certainty.



This equipment is mainly applied in metal such as food chemical, pharmaceutical industry and non-metal foreign materials, defect (damage) inspection, all-round inspection of foreign materials, including metal, non-metal foreign materials (glass, ceramics, stones, bones, hard rubber, hard plastics, etc.). It can detect metals, non-metallic packaging and canned goods without limited product properties. It also is not affected by changes in temperature and humidity, and salt content. The back-end sorting can be used to sort the problematic products and the qualified products continue to flow.


Model UNF6040
Max Voltage 40-120kV
Max Current 0.2-7.5mA
Inspection Speed (m/min) 10-50
Inspection Accuracy(mm) Stainless steel ball ø0.5,Stainless steel wire 0.2x1.5, Glass2.0,Plastic 1.5
Image system Linear detector array
Belt Food grade belt, length can be customized
Tunnel Size(mm) 600x400
Max.Loading Weight 10kg
Monitor 19''
Dimension(WxDxH,mm) 1600x790x1800
Weight 500kg
Safety <1μSv/h (5cm away from the housing)
Operation 1-2person (Can be fully automated with automatic line docking)
Equipment material 304Stainless steel
Software Unicomp Software
Applications Bulk, metal (or non-metal) packaging and canning
Radiation Safety Statement :All the equipments produced by Unicomp Technology meet the relevant requirements of the national standard GB18871-2002, which is better than the industry average.
Work environment : Temperature -5-40°C , Humidity 10-90% (No condensation)



FAQ


1. Are you manufacturer or trader?


We are manufacturer, we have own factory in Wuxi , Shenzhen ,Chongqing, we have independent department for purchasing, producing, processing, testing, packing, storing , and transportation .



2.How about the packing for product? Is it easy damaged during transportation?


For heavy structure products like conveyor belt needle detector. Food metal detector X ray machine .Our packing is Standard Export ploy Wooden Case.



3.How about your after-sales policy?


Customer first is our always principle. All of our products normal warranty is 12months. We give necessary back or video guidance for daily problems. If massive products occur big quality problems. Our technical and engineer support overseas service .
